Yorkville - C170P

Description

The C170P is a powered version of the C170, which is based on the already popular C110, C120 and C130, which have a complete list of features that make them an extremely good value for fixed installations. The C170P, is a compact 100 watt powered loudspeaker enclosure made from ABS plastic with an 8-inch driver and 1-inch Mylar tweeter, and features 1/4" input and output connectors for maximum versatility.

The trapezoidal shape makes the C170P ideal for install or array mounting in tight locations. Shipped with a rugged proprietary U-bracket for wall or ceiling mounting, they are a very versatile and cost-effective solution where superior sonic quality is required for small installations, or as a repeater or fill cabinet in larger venues. An optional polemount adapter (C170ADAPT) is also available for applications where placing the C170P on a speaker stand is required.

Exclusive features to the C170P include a 1/4" input and auxiliary out, controls for Gain, Volume and Tone, with a switchable mic/line input sensitivity, and a power switch.

Features:
* High Performance Active Two-Way Loudspeaker
* 8-inch Woofer / 1-inch Mylar Dome Tweeter
* 100 Watt Integrated Amplifier
* 1/4-inch TRS Balanced Inputs
* Accepts Microphone or Line Level Inputs
* Gain, Volume and Tone Controls
* Heavy Duty ABS Plastic Cabinet and Metal Grille
* Mounting U-Bracket Included
* Optional Stand-Mount Adaptor (C170ADAPT) is Available

Specifications:
* System Type: 2-Way
* Active or Passive: Active
* Program Power (Watts): 100
* Max SPL (dB): 113
* Frequency Response (Hz +/- 3dB): 60 - 20,000
* Driver Configuration: 8 inch / 1 inch dome tweeter
* HF Driver(s): 1 inch Mylar Dome Tweeter
* LF Driver(s): 8 inch
* Total Power (Watts): 100
* Cooling Scheme: Heat Sink
* Power Cable: Built-in
* Power Switch: Yes
* Inputs: 2 x 1/4inch TRS (Input/Aux Out)
* Inputs - 1/4 IN Jacks: 1 TRS
* Mixer Controls: Mic/Line sensitivity switch Gain, Tone, Volume controls
* Feet: Yes
* Included Hardware: Mounting Bracket
* Pole Mount Adapter (1 3/8 IN -3.5cm): Optional Adapter (C170ADAPT)
* Enclosure Materials: ABS Plastic
* Grille: Perforated Metal
* Dimensions (DWH xbackW COM inches): 11.25 x 9.75 x 16.25 x 9.5
* Dimensions (DWH xbackW COM cm): 28.5 x 25 x 42 x 24
* Weight (lbs/kg): 18.7 / 8.5
