Pioneer DJ Tour System 4-Channel Digital Mixer w/Touch Screen
Additional Photos:
Product Videos :
The CDJ-TOUR1 multiplayer and DJM-TOUR1 mixer take the professional sound quality of the NXS2 set-up and add the components needed to deliver that performance in large venues such as festivals and arenas. Both models have an ESS Technology 32-bit D/A converter to eliminate low noise and distortion and give a clear, crisp sound at scale. The DJM-TOUR1 is the first mixer to have a pro audio grade AES/EBU digital output, so you can connect directly to front of house even over long distances with no loss of sound quality.
The 13-inch, full-colour touch screens with built-in CPU give you effortless control: you can browse faster, grasp waveforms more easily, and do it all while keeping the crowd in your line of sight. And back-to-back DJing is a breeze, thanks to the DJM-TOUR1s two independent headphone sections that let you monitor and cue tracks separately.
The TOUR1 set-up is as sturdy as the name suggests, with reinforced sides, lockable NEUTRIK etherCON LAN ports and gold-plated RCAs making it a stable set-up you can count on in any large-scale environment.
KEY FEATURES
Warm Sound at Any Venue
A 32-bit D/A convertor, made by ESS Technologies, delivers incredibly low noise and distortion even at super-high volumes. Additionally the 96 kHz/24-bit sound card, 64-bit floating point mixing processing, enhanced dithering technology and a low-jitter clock combine to provide an accurate, natural analogue sound.
Connect to Front of House
The AES/EBU digital output lets you connect directly to the PA, regardless of its positioning. Together with the word clock input it ensures high-grade digital audio signal transmission to front of house for precise synchronisation and the best possible sound quality.
13-inch Fold-Out Touch Screen
Use multicoloured touch display to browse and select tracks from up to 4 CDJs connected via Pro DJ Link. Choose between a horizontal multi-wave view or a vertical view that also includes an RMS meter so you can monitor and control the volume for each channel.
5-Port LAN Hub
A 5-port LAN hub means you can connect up to 5 players or laptops to the DJM-TOUR1. Via Pro DJ Link you can share one source across up to 4 players and if you're using rekordbox dj you get access to a host of advanced performance features on top.
Easy B2B Cueing
2 independent headphone sections let you and another DJ cue tracks at the same time without hearing each other's input. Each headphone also has its own volume control for ease and comfort.
Sound Color FX
6 studio-quality sound FX - Sweep, Filter, Crush, Dub Echo, Noise and Space - are available on every channel. Use the parameter control knob to fine-tune the FX.
Built-in KUVO Gateway
The DJM-TOUR1 is Pioneer's first mixer to have a KUVO Gateway on board so you can easily connect to KUVO and broadcast your set information, in real time, to fans around the world.
SPECS
MIDI Control: Full assignable MIDI controls
DVS Control: rekordbox dvs (not included)
ProDJ Link: Yes
P-LOCK Fader Caps: Yes
Auto Standby: Yes
General
• Dimensions (with fold-out display)
When upper display part is closed (W x D x H): 445.2 x 451.6 x 179.1 mm
When upper display part is upright at 90 degrees (W x D x H): 445.2 x 457.8 x 418 mm
When upper display part is fully open (W x D x H): 445.2 x 694.5 x 203.1 mm
• Weight: 16.1 kg
• Frequency Range: 20 - 40,000 Hz
• Sampling Rate: 96 kHz
• A/D Converter: 24 bit
• D/A Converter: 32 bit
• S/N Ratio Line: 105 dB
• S/N Ratio Phono: 88 dB
• S/N Ratio Mic: 79 dB
• Distortion: < 0.005 % (LINE)
• Power Consumption: 66 W
Channels
EQ/ISO: 3 band
EQ/ISO Range: Built-in, switchable 3-band equaliser: -26 dB ~ +6 dB / 3-band isolator: -∞ ~ +6 dB
Crossfader
Crossfader Type: Magvel Fader
Mic
Mic Connection: XLR / 1/4-inch Jack Combo; 1/4-inch TRS Jack
Talkover: 3 Position Switch
Terminals
Inputs
• 4 Digital (Coaxial)
• 4 CD/LINE (RCA)
• 4 PHONO (RCA)
• 1 AUX (XLR, 1/4 inch TRS Jack)
• 2 MIC (XLR/TRS Jack Combo, 1/4 inch TRS Jack)
• 1 Word Clock (BNC)
Outputs
• 2 MASTER (XLR, RCA)
• 1 BOOTH (XLR)
• 2 HEADPHONE MONITOR (1/4 inch Jack, mini-jack)
• 1 HEADPHONE MONITOR (1/4 inch Jack)
• 1 REC (RCA)
• 1 Digital (XLR)
Send/Return
• 1 SEND (1/4-inch TS jack)
• 1 RETURN (1/4-inch TS jack)
LAN
• 6
USB
• 2 USB B ports
1 USB A port
Media
