BOSS GX-10 Guitar Effects Processor
Additional Photos:
Your Price: $539.99 CDN
or from $57 CDN/mo
Colorful Tones, Portable Design
Players everywhere love the GX-100 for its streamlined design, free-flowing interface, and high-quality tones. Armed with the core GX-100 engine, the compact GX-10 brings you the same inspiring experience in an even more portable footprint. You get loads of AIRD amps and effects for covering every style, plus speedy sound building with the intuitive color touch display and panel knobs. Adding in multi-mode footswitches, an integrated expression pedal, and USB audio connectivity, the GX-10 seamlessly transitions from nightly stage performing to desktop recording, song creation, and daily practice sessions.
No-Compromise Sound Quality
The GX-10 brings you a universe of ultra-responsive BOSS tone processing in a travel-ready size. Take on every playing situation with 23 guitar amps and nine bass amps, including high-gain X-Ultra, X-Optima, and X-Titan types crafted with our latest technologies. And let your imagination run wild with 170 effects, including overdrives and distortions, mod effects, delays, and reverbs, plus dedicated bass effects and BOSS classics like Slow Gear, Octave, Slicer, and more.
Build Great Sounds Fast
The GX-10 enables fast sound creation with its inviting color touch display and four dynamic parameter knobs. Assign up to two amps and 15 effects in each memory. Create serial or parallel effect routings and change the order by dragging blocks with a finger on the screen. And patch in your go-to external pedals with the send/return loop. BOSS Tone Studio takes things even further, allowing you to edit sounds and load IRs from your computer or wirelessly tweak tones via our optional Bluetooth adaptor and the mobile version of the app.
Flexible Real-Time Command
Packing clever control options into a minimal layout, the GX-10 gives you powerful tools for real-time sound adjustment while performing. Versatile control modes provide maximum flexibility with just three footswitches. The expression pedal toggles between volume and wah and activates the tuner when you pull the pedal back. But you can customize it to control nearly anything you want with the GX-10's assign matrix.
Up/Down Mode: Simplify your rig by scrolling through memories one at a time. Set up basic memories for clean, crunch rhythm, and lead sounds. Or load up the 66 banks and 198 user memories with custom sounds for your set list and tap through them sequentially on stage.
Manual Mode: This reconfigures the footswitches to control three user-assignable targets. Use them like a pedalboard to turn effects on/off or kick in a solo boost. Or go deeper by changing up to 20 assignable parameters with just one press.
Bank/Number Mode: This mode allows you to select memories within banks. It also unlocks the Current Number function, providing access to one or more parameters by pressing the switch for the currently loaded memory. Using this function, you can extend your tonal options for each memory with a solo boost, delay effect, or anything else you'd like to assign.
Organize and Record
In addition to editing, BOSS Tone Studio allows you to organize GX-10 sounds into Livesets for different gigs and playing situations. You can also access BOSS Tone Exchange within the app to download professionally created sounds and share GX-10 Livesets with the global BOSS community. GX-100 Livesets are fully compatible with the GX-10 as well. In addition, there's a built-in USB-C audio interface for capturing high-quality guitar tones in music production apps on computers and mobile devices.
• The same sound engine and color touch display as the GX-100 in a portable, travel-ready design
• Exceptional audio quality with 24-bit AD and 32-bit DA conversion, 32-bit floating-point processing, and 48 kHz sampling rate
• Authentic tube amplifier tone and touch response with AIRD technology
• 32 amplifier types and 170 BOSS effects
• Ultra-flexible amp/effect routing up to 15 assignable blocks
• Wide selection of onboard speaker types and support for loading WAV speaker IRs
• Streamlined modern design with a rugged metal chassis
• Three footswitches with flexible control modes
• Onboard expression pedal with toe switch
• Connect up to two footswitches or an expression pedal for expanded control
• Send/return loop for external pedals
• Record and play tracks in music production software on a computer or mobile device• via a USB-C®
• Edit sounds from your computer with BOSS Tone Studio for macOS and Windows
• Download and share Livesets at BOSS Tone Exchange (compatible with GX-100 Livesets)
• Optional Bluetooth® Audio MIDI Dual Adaptor allows you to edit sounds and stream audio from an iOS or Android mobile device
- 48 kHz
AD Conversion
- 24 bits + AF method
DA Conversion
- 32 bits
Processing
- 32-bit floating point
Effects
- 170 Types
Maximum Number of Effects
- 15+3 (DIVIDER/MIXER, SEND/RETURN, PHRASE LOOP)
Memories
- 198 (User) + 99 (Preset)
Phrase Loop
- 38 sec. (MONO)
- 19 sec. (STEREO)
Tuner Internal Detection
- +/-0.1 cent
Nominal Input Level
- INPUT: -10 dBu
- RETURN: -10 dBu
Maximum Input Level
- INPUT: +7 dBu
- RETURN: +7 dBu
Input Impedance
- INPUT: 1 M ohm
- RETURN: 1 M ohm
Nominal Output Level
- OUTPUT (L/MONO, R): -10 dBu
- PHONES: -10 dBu
- SEND: -10 dBu
Output Impedance
- OUTPUT (L/MONO, R): 1 k ohm
- PHONES: 44 ohms
- SEND: 1 k ohm
Recommended Load Impedance
- OUTPUT (L/MONO, R): 10 k ohms or greater
- PHONES: 44 ohms or greater
- SEND: 10 k ohms or greater
Controls
- DOWN switch, UP switch, CTL1 switch, POWER switch, EXP1 switch,
- PAGE button, MENU button, EFFECTS button, EXIT button, WRITE button, 1-4 knobs, SELECT knob, OUTPUT LEVEL knob, EXP1 pedal
Display
- Color Graphic LCD (480 x 272 dots) Touch screen
Connectors
- INPUT jack, OUTPUT (L/MONO, R) jacks, SEND jack, RETURN jack: 1/4-inch phone type, PHONES jack: Stereo 1/4-inch phone type
- CTL2,3/EXP2 jack: 1/4-inch TRS phone type
- USB COMPUTER port: USB Type-C(R)
- Bluetooth ADAPTOR connector: Dedicated connector
- DC IN jack
Power Supply
- AC adaptor
Current Draw
- 600 mA
Dimensions
- 300 (W) x 183 (D) x 74 (H) mm (11-13/16 (W) x 7-3/16 (D) x 2-15/16 (H)")
Maximum height
- 300 (W) x 183 (D) x 96 (H) mm (11-13/16 (W) x 7-3/16 (D) x 3-3/4 (H)")
Weight
- 2.2 kg (4 lbs 14 oz)
Players everywhere love the GX-100 for its streamlined design, free-flowing interface, and high-quality tones. Armed with the core GX-100 engine, the compact GX-10 brings you the same inspiring experience in an even more portable footprint. You get loads of AIRD amps and effects for covering every style, plus speedy sound building with the intuitive color touch display and panel knobs. Adding in multi-mode footswitches, an integrated expression pedal, and USB audio connectivity, the GX-10 seamlessly transitions from nightly stage performing to desktop recording, song creation, and daily practice sessions.
No-Compromise Sound Quality
The GX-10 brings you a universe of ultra-responsive BOSS tone processing in a travel-ready size. Take on every playing situation with 23 guitar amps and nine bass amps, including high-gain X-Ultra, X-Optima, and X-Titan types crafted with our latest technologies. And let your imagination run wild with 170 effects, including overdrives and distortions, mod effects, delays, and reverbs, plus dedicated bass effects and BOSS classics like Slow Gear, Octave, Slicer, and more.
Build Great Sounds Fast
The GX-10 enables fast sound creation with its inviting color touch display and four dynamic parameter knobs. Assign up to two amps and 15 effects in each memory. Create serial or parallel effect routings and change the order by dragging blocks with a finger on the screen. And patch in your go-to external pedals with the send/return loop. BOSS Tone Studio takes things even further, allowing you to edit sounds and load IRs from your computer or wirelessly tweak tones via our optional Bluetooth adaptor and the mobile version of the app.
Flexible Real-Time Command
Packing clever control options into a minimal layout, the GX-10 gives you powerful tools for real-time sound adjustment while performing. Versatile control modes provide maximum flexibility with just three footswitches. The expression pedal toggles between volume and wah and activates the tuner when you pull the pedal back. But you can customize it to control nearly anything you want with the GX-10's assign matrix.
Up/Down Mode: Simplify your rig by scrolling through memories one at a time. Set up basic memories for clean, crunch rhythm, and lead sounds. Or load up the 66 banks and 198 user memories with custom sounds for your set list and tap through them sequentially on stage.
Manual Mode: This reconfigures the footswitches to control three user-assignable targets. Use them like a pedalboard to turn effects on/off or kick in a solo boost. Or go deeper by changing up to 20 assignable parameters with just one press.
Bank/Number Mode: This mode allows you to select memories within banks. It also unlocks the Current Number function, providing access to one or more parameters by pressing the switch for the currently loaded memory. Using this function, you can extend your tonal options for each memory with a solo boost, delay effect, or anything else you'd like to assign.
Organize and Record
In addition to editing, BOSS Tone Studio allows you to organize GX-10 sounds into Livesets for different gigs and playing situations. You can also access BOSS Tone Exchange within the app to download professionally created sounds and share GX-10 Livesets with the global BOSS community. GX-100 Livesets are fully compatible with the GX-10 as well. In addition, there's a built-in USB-C audio interface for capturing high-quality guitar tones in music production apps on computers and mobile devices.
Features
• Compact amp/effects processor for guitar and bass• The same sound engine and color touch display as the GX-100 in a portable, travel-ready design
• Exceptional audio quality with 24-bit AD and 32-bit DA conversion, 32-bit floating-point processing, and 48 kHz sampling rate
• Authentic tube amplifier tone and touch response with AIRD technology
• 32 amplifier types and 170 BOSS effects
• Ultra-flexible amp/effect routing up to 15 assignable blocks
• Wide selection of onboard speaker types and support for loading WAV speaker IRs
• Streamlined modern design with a rugged metal chassis
• Three footswitches with flexible control modes
• Onboard expression pedal with toe switch
• Connect up to two footswitches or an expression pedal for expanded control
• Send/return loop for external pedals
• Record and play tracks in music production software on a computer or mobile device• via a USB-C®
• Edit sounds from your computer with BOSS Tone Studio for macOS and Windows
• Download and share Livesets at BOSS Tone Exchange (compatible with GX-100 Livesets)
• Optional Bluetooth® Audio MIDI Dual Adaptor allows you to edit sounds and stream audio from an iOS or Android mobile device
Specifications
Sampling Frequency- 48 kHz
AD Conversion
- 24 bits + AF method
DA Conversion
- 32 bits
Processing
- 32-bit floating point
Effects
- 170 Types
Maximum Number of Effects
- 15+3 (DIVIDER/MIXER, SEND/RETURN, PHRASE LOOP)
Memories
- 198 (User) + 99 (Preset)
Phrase Loop
- 38 sec. (MONO)
- 19 sec. (STEREO)
Tuner Internal Detection
- +/-0.1 cent
Nominal Input Level
- INPUT: -10 dBu
- RETURN: -10 dBu
Maximum Input Level
- INPUT: +7 dBu
- RETURN: +7 dBu
Input Impedance
- INPUT: 1 M ohm
- RETURN: 1 M ohm
Nominal Output Level
- OUTPUT (L/MONO, R): -10 dBu
- PHONES: -10 dBu
- SEND: -10 dBu
Output Impedance
- OUTPUT (L/MONO, R): 1 k ohm
- PHONES: 44 ohms
- SEND: 1 k ohm
Recommended Load Impedance
- OUTPUT (L/MONO, R): 10 k ohms or greater
- PHONES: 44 ohms or greater
- SEND: 10 k ohms or greater
Controls
- DOWN switch, UP switch, CTL1 switch, POWER switch, EXP1 switch,
- PAGE button, MENU button, EFFECTS button, EXIT button, WRITE button, 1-4 knobs, SELECT knob, OUTPUT LEVEL knob, EXP1 pedal
Display
- Color Graphic LCD (480 x 272 dots) Touch screen
Connectors
- INPUT jack, OUTPUT (L/MONO, R) jacks, SEND jack, RETURN jack: 1/4-inch phone type, PHONES jack: Stereo 1/4-inch phone type
- CTL2,3/EXP2 jack: 1/4-inch TRS phone type
- USB COMPUTER port: USB Type-C(R)
- Bluetooth ADAPTOR connector: Dedicated connector
- DC IN jack
Power Supply
- AC adaptor
Current Draw
- 600 mA
Dimensions
- 300 (W) x 183 (D) x 74 (H) mm (11-13/16 (W) x 7-3/16 (D) x 2-15/16 (H)")
Maximum height
- 300 (W) x 183 (D) x 96 (H) mm (11-13/16 (W) x 7-3/16 (D) x 3-3/4 (H)")
Weight
- 2.2 kg (4 lbs 14 oz)
Q & A
There are currently no questions for this product.
Reviews
13.58.105.80
Mozilla/5.0 AppleWebKit/537.36 (KHTML, like Gecko; compatible; ClaudeBot/1.0; [email protected])
Smaller GX-100 while keeping all features. 7 of 7 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Kingston, Ontario
I had a GX-100 and though I really liked it, it was too large, heavy and bulky. It worked well as a tool for playing live, but not so great for practicing in the living room and office and travelling. Even moving it up and downstairs in my house was a bit of a pain.
This unit has a much more reasonable size and weight while keeping 100% of the core GX functionality. It works much better for me.
The complaints:
- I wish it had one more foot switch (but this can be addressed by using an external one when needed).
- The second complaint is that the expression pedal is plastic while the one in the GX-100 was metal.
- Also though it is touch screen, the UI could have used a little improvement. I.e. a real touchscreen keyboard for typing patch names instead of having to use a scroll wheel. This could be fixed with a software update, though I know BOSS rarely does that.
As for the sounds, that's very subjective. All I can say is that I like the sounds better than the ones in my POD GO. To me it sounds good, no complaints.
Posted by Ivan on Nov 5, 2024
this is the Muti effects I have been waiting for 4 of 5 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Kanata, Ontario
small footprint.
all boss effects.
touch screen drag and drop.
bluetooth mobile app.
I sold all of my effects and bought this unit.
this unit does everything I need and it is a lot less money than a line 6 HX effects pedal
Posted by Gary Atkins on Nov 4, 2024
Love it 1 of 6 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store St. Catharines, Ontario
This is a great unit. If your looking for ambient patches, this works very well, between all the reverbs and delays. Lots of different option with 170 effects to choose from. Easy to make patches.
Posted by Kevin on Nov 1, 2024
