PreSonus Quantum ES 4 USB-C Audio Interface
Additional Photos:
Your Price: $459.99 CDN
or from $49 CDN/mo
Capture your creativity with the Quantum ES 4. The next generation of PreSonus audio interfaces, the Quantum ES 4 is the culmination of nearly 30 years of PreSonus expertise, providing the ultimate recording tool for musicians and content creators.
• All-New MAX-HD Mic Preamps The culmination of 30 years of innovation, our rigorously redesigned preamps feature digitally-controlled analog with +75 dB of gain range.
• Co-Developed with Fender® Front-facing instrument inputs engineered for guitarists by industry-leading experts.
• Professional Recording Software Included 6 months of Studio One+ with full access to Studio One Professional Edition, add-ons, and more.
• Auto Gain Dial in recording-ready levels, hassle-free.
• Universal Control App Full control and metering from your mobile device, desktop, or tablet.
Headphone Jack: Two - 1/4" TRS Female Stereo
Connectivity: USB-C®
Voltage: 120V
Phantom Power: +48 VDC
Performance
Digital Audio Bit Depth: 24-bit
Digital Audio Dynamic Range: 120 dB
Inputs
Instrument Inputs Dynamic Range: 111 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz)
Instrument Inputs Gain Range: 75 dB
Instrument Inputs Maximum Level: +15 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range: 114 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz)
Line Inputs Gain Range: +/- 10 dB
Line Inputs Impedance: 10K Ohms
Line Inputs Maximum Level: +15 dBu (Balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion: 0.001% (1 kHz, Minimum Gain)
Microphone Input Connection Type: XLR Female (Combo), Balanced
Microphone Preamp Dynamic Range: 113 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise: -129 dBu (Maximum Gain, 150 Ohms, 22 kHz BW, A-Weighted)
Microphone Preamp Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz)
Microphone Preamp Gain Control Range: 75 dB
Microphone Preamp Input Impedance: 1600 Ohms
Microphone Preamp Maximum Input Level: +14 dBu (Balanced, Minimum Gain)
Microphone Preamp Total Harmonic Distortion: .001% (1 kHz, Minimum Gain)
Outputs
Headphone Outputs Dynamic Range: 111 db (a-weighted)
Headphone Outputs Frequency Response: 20 hz to 20 khz, +/- 0.2 db (unity gain, reference 1 khz)
Headphone Outputs Impedance Working Range: 22 ohms
Headphone Outputs Maximum Output: 7.5 dbu (50 ohms)
Headphone Outputs Total Harmonic Distortion: 0.02% (1 khz)
Line Outputs Connection Type: 1/4" TRS Female
Main and Line Outputs Dynamic Range: 117 db (a-weighted)
Main and Line Outputs Frequency Response: 20 hz to 20 khz, +/- 0.1 db (unity gain, reference 1 khz)
Main and Line Outputs Maximum Level: +15 dbu (balanced)
Main and Line Outputs Impedance: 51 ohms
Main and Line Outputs Total Harmonic Distortion: 0.001% (1 khz, +4 dbu)
Main Outputs Connection Type: 1/4" trs female
Hardware
MIDI IO: 3.5 mm Type-B
Features
• High Performance Signal Flow Custom low-latency drivers and low-noise converters.• All-New MAX-HD Mic Preamps The culmination of 30 years of innovation, our rigorously redesigned preamps feature digitally-controlled analog with +75 dB of gain range.
• Co-Developed with Fender® Front-facing instrument inputs engineered for guitarists by industry-leading experts.
• Professional Recording Software Included 6 months of Studio One+ with full access to Studio One Professional Edition, add-ons, and more.
• Auto Gain Dial in recording-ready levels, hassle-free.
• Universal Control App Full control and metering from your mobile device, desktop, or tablet.
Specifications
ElectronicsHeadphone Jack: Two - 1/4" TRS Female Stereo
Connectivity: USB-C®
Voltage: 120V
Phantom Power: +48 VDC
Performance
Digital Audio Bit Depth: 24-bit
Digital Audio Dynamic Range: 120 dB
Inputs
Instrument Inputs Dynamic Range: 111 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz)
Instrument Inputs Gain Range: 75 dB
Instrument Inputs Maximum Level: +15 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range: 114 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz)
Line Inputs Gain Range: +/- 10 dB
Line Inputs Impedance: 10K Ohms
Line Inputs Maximum Level: +15 dBu (Balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion: 0.001% (1 kHz, Minimum Gain)
Microphone Input Connection Type: XLR Female (Combo), Balanced
Microphone Preamp Dynamic Range: 113 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise: -129 dBu (Maximum Gain, 150 Ohms, 22 kHz BW, A-Weighted)
Microphone Preamp Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz)
Microphone Preamp Gain Control Range: 75 dB
Microphone Preamp Input Impedance: 1600 Ohms
Microphone Preamp Maximum Input Level: +14 dBu (Balanced, Minimum Gain)
Microphone Preamp Total Harmonic Distortion: .001% (1 kHz, Minimum Gain)
Outputs
Headphone Outputs Dynamic Range: 111 db (a-weighted)
Headphone Outputs Frequency Response: 20 hz to 20 khz, +/- 0.2 db (unity gain, reference 1 khz)
Headphone Outputs Impedance Working Range: 22 ohms
Headphone Outputs Maximum Output: 7.5 dbu (50 ohms)
Headphone Outputs Total Harmonic Distortion: 0.02% (1 khz)
Line Outputs Connection Type: 1/4" TRS Female
Main and Line Outputs Dynamic Range: 117 db (a-weighted)
Main and Line Outputs Frequency Response: 20 hz to 20 khz, +/- 0.1 db (unity gain, reference 1 khz)
Main and Line Outputs Maximum Level: +15 dbu (balanced)
Main and Line Outputs Impedance: 51 ohms
Main and Line Outputs Total Harmonic Distortion: 0.001% (1 khz, +4 dbu)
Main Outputs Connection Type: 1/4" trs female
Hardware
MIDI IO: 3.5 mm Type-B
Q & A
Question: Will it work with my Lenovo P52 Thinkpad and Ubuntu 24.04?
- asked on Oct 15, 2024
- asked on Oct 15, 2024
Answer: I would check the Presonus website to see if they will have a compatible driver for your system.
- answered by Bradford Pettigrew, Edmonton Highlands, Alberta
- answered by Bradford Pettigrew, Edmonton Highlands, Alberta
Reviews
18.225.56.181
Mozilla/5.0 AppleWebKit/537.36 (KHTML, like Gecko; compatible; ClaudeBot/1.0; [email protected])
My Review of PreSonus Quantum ES 2 and ES 4 Audio Interfaces 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Edmonton Highlands, Alberta
Review of PreSonus Quantum ES 2 and ES 4 Audio Interfaces
The PreSonus Quantum ES 2 and ES 4 audio interfaces are standout products in the realm of home and professional studio setups. These interfaces are celebrated for their high-quality sound and robust build, making them a top choice for audio enthusiasts and professionals alike.
Key Features
1. Exceptional Sound Quality: Both the Quantum ES 2 and ES 4 are equipped with MAX-HD preamps, which deliver an impressive +75 dB of gain range. This ensures that the sound captured is clear, dynamic, and free from unwanted noise.
2. Versatile Connectivity:
- Quantum ES 2: Offers a compact 2×2 interface, perfect for on-the-go recordings and simple setups.
- Quantum ES 4: Steps up with 4×4 connectivity, providing more inputs and outputs for versatile recording scenarios.
3. User-Friendly Design: The interfaces are designed to fit seamlessly into any workspace. They are compact enough for small setups but offer enough features to avoid compromising on functionality.
4. Innovative Features:
- Co-developed Inputs with Fender®: These inputs are engineered to deliver the finest tone and response, especially beneficial for guitarists.
- Zero-Latency Monitoring: Ensures a smooth recording process without technical distractions.
- Universal Control App: Allows full control and metering from your devices, making it easy to adjust settings on the fly.
Appreciation for PreSonus
PreSonus has truly outdone itself with the Quantum ES series. The research and development that went into the MAX-HD preamps is evident in the superior sound quality these interfaces provide. The collaboration with Fender for the instrument inputs further highlights PreSonus's commitment to delivering top-notch audio solutions.
In summary, the PreSonus Quantum ES 2 and ES 4 are excellent choices for anyone looking to enhance their audio recording and production capabilities. Their combination of high-quality sound, versatile connectivity, and user-friendly design makes them a valuable addition to any studio setup.
Posted by RADJABU MUKUMBILWA on Oct 21, 2024
Addendum to my original review 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Edmonton Whyte, Alberta
Of course the Quantum ES 4 offers mic gain of up to 75dB, not "up to 70dB" as I wrote below. And even at the highest setting you will hear very little noise. The noise is there (at around 70dB), but it is negligible, even on quiet acoustic sources. I use the ES 4 with my ribbon mics, which work well at between 60 and 65dB.
Posted by Piotr Grella-Mozejko on Jul 7, 2024
Best in its class - a sure winner 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Edmonton Whyte, Alberta
The Quantum ES 4 is excellent. When you consider its price, at the moment (July 2024) there is no similar interface on the market, that is better. Some units, like Arturia interfaces, may offer a few more bells and whistles, but what sets the ES 4 apart, head and shoulders above the rest, is its overall simple and effective design.
1) The interface is well built and you know right out of the box that it will last.
2) It uses digital circuits, which make its use a pleasure (I am a big fan of digital interfaces; this is precisely why I loved the old Roland Octa-Capture, which I consider a classic, one of the best interfaces ever made).
3) It is extremely easy to use and program. It just cannot be simpler. It will save you a lot of time because the accompanying digital mixer offers an elegant overview of your settings. I am not going to write more about it because the manual explains it all in the simplest (idiot-proof, ha ha) terms. I will only say that you can determine your setting either via the digital console or via combination of the main knob and the top panel buttons. Easy peasy. And the digital lighting colour scheme (blue, green, white, red) makes the whole process even simpler.
4) The preamps, which give you up to 70dB gain, are very quiet, very neutral (which I appreciate immensely), and clean. They really are THAT good. Naturally, since everything is digitised, you may use any combination of mics - phantom power is applicable separately to each channel. And you will not need any extra preamp, or in-line preamp, to use the power-hungry dynamic mics such as the SM58, or ribbons.
5) Headphone outputs - there are two - are at least ample.
6) PreSonus designed "no-latency" drivers for the new generation of Quantum interfaces - and it actually shows. These drivers are quite good indeed and you will be able to use the ES 4 at very low buffer sizes (PreSonus calls them "block sizes"). A buffer of 64 samples seems to be a safe bet.
(*) One caveat: on a Mac, even an older one (we're talking 2016-2018 MacBook Pro models) you can use this interface powered by USB/TB ports. Not so on Windows PCs and/or laptops (I tried three recent models - one top-of-the-line desktop and two powerful gaming laptops, which I use for my recording, editing, mixing and mastering work). For the latter you will need to purchase an external charger (I bought the NENASEW 100W charger on Amazon.ca, which works beautifully and is not expensive).
The Quantum ES 4 is a perfect choice even for professional musicians and producers. Bigger studious will certainly opt for the Quantum HD models, but I assure you that the ES 4 will do a perfect job, be it recording or performing live.
Posted by Piotr Grella-Mo?ejko on Jul 4, 2024
