Intellijel Pedal I/O 1U Effects Pedal Send/Return Module
Product Videos :
YouTube Video
YouTube Video
Rack meet Guitar; Guitar meet rack
Open your rack to the world of guitar effects: delays, choruses, flangers, phasers, fuzz boxes, tremolos, wah-wahs, amp simulators, compressors, pitch shifter, and more.
Open your guitar to the world of eurorack: filters, ring mods, wave folders, sequencers, and most importantly the unique CV modulation delights inherent to your rack.
Best Of Both Worlds
The Pedal I/O 1U system enables the modular synthesist to interact with the impressive assortment of delays, choruses, flangers, phasers, fuzz boxes, tremolos, wah-wahs, amp simulators, compressors and pitch shifter pedals available to guitarists. Conversely, it also grants guitarists access to the myriad filters, ring mods, wavefolders and - most importantly - the near infinite CV modulation delights inherent in eurorack. The Pedal I/O is more than just a simple level shifter - it's also an impedance converter, which provides proper drive and loading for any FX pedals or instruments you connect.
The Pedal Interface 1U module connects either to the Pedal I/O Jacks 1U module, or directly to the 7U cases using the 7U Case Adaptor. Two Pedal Interface modules can be connected to a 7U case in this manner, with one taking the left input and output on the case, while other takes the right.
• Signals arriving at the Pedal I/O System pass through a Class A triode emulator, allowing for some tube-like overdrive at high gain setting
• Separate gain controls on both the SEND and RETURN
• Use Pedal I/O in the studio as an active "re-amping" device to play pre-recorded tracks back through guitar amplifiers or pedals
• Low MIX output impedance for driving long cables, lower noise, and minimum interference from outside sources
• Switch to invert phase of the return signal
• Switch to select line or pedal/instrument level output
Depth: 29mm
Power: 10mA @ 12V, 10mA @ -12V
Open your rack to the world of guitar effects: delays, choruses, flangers, phasers, fuzz boxes, tremolos, wah-wahs, amp simulators, compressors, pitch shifter, and more.
Open your guitar to the world of eurorack: filters, ring mods, wave folders, sequencers, and most importantly the unique CV modulation delights inherent to your rack.
Best Of Both Worlds
The Pedal I/O 1U system enables the modular synthesist to interact with the impressive assortment of delays, choruses, flangers, phasers, fuzz boxes, tremolos, wah-wahs, amp simulators, compressors and pitch shifter pedals available to guitarists. Conversely, it also grants guitarists access to the myriad filters, ring mods, wavefolders and - most importantly - the near infinite CV modulation delights inherent in eurorack. The Pedal I/O is more than just a simple level shifter - it's also an impedance converter, which provides proper drive and loading for any FX pedals or instruments you connect.
The Pedal Interface 1U module connects either to the Pedal I/O Jacks 1U module, or directly to the 7U cases using the 7U Case Adaptor. Two Pedal Interface modules can be connected to a 7U case in this manner, with one taking the left input and output on the case, while other takes the right.
Features
• Use the Pedal I/O's RETURN circuit as a "direct box" for connecting any instrument• Signals arriving at the Pedal I/O System pass through a Class A triode emulator, allowing for some tube-like overdrive at high gain setting
• Separate gain controls on both the SEND and RETURN
• Use Pedal I/O in the studio as an active "re-amping" device to play pre-recorded tracks back through guitar amplifiers or pedals
• Low MIX output impedance for driving long cables, lower noise, and minimum interference from outside sources
• Switch to invert phase of the return signal
• Switch to select line or pedal/instrument level output
Specifications
Width: 16HPDepth: 29mm
Power: 10mA @ 12V, 10mA @ -12V
Media
Youtube video product demo
Youtube video product demo
Q & A
There are currently no questions for this product.
Reviews
There are currently no reviews for this product. Be the first to write one!
