Celestion G10 Gold Alnico Guitar Speaker - 8 Ohm
Additional Photos:
Product Videos :
YouTube Video
Following the great reviews Celestion received for the Gold 12", they realised there was also a need for a speaker that conveyed the Alnico mellowness of the original Blue, with the speed and response of a 10" driver. The G10 Gold is the ultimate 10" guitar speaker, blending unmistakable Alnico class with a rich low-end, creamy mid-range and vintage chiming top-end.
Springy, warm, revealing and highly expressive, it can be used singly or in pairs to add a classy sheen to any amp, or in a 4x10 configuration for higher volume depth, warmth and shimmer, with less of the boom associated with 4x12 cabinets.
Power Rating: 40W
Rated Impedance: 8Ω
Sensitivity: 98dB
Chassis Type: Pressed steel
Magnet Type: Alnico
Voice Coil Diameter: 1.75" (44.5 mm)
Voice Coil Material: Round copper
Frequency Range: 80-6000Hz
Resonance Frequency, Fs: 80Hz
DC Resistance, Re: 6.66Ω and 13.56Ω
Diameter: 256 mm (10.1")
Magnet Structure Diameter: 119 mm (4.7")
Mounting Hole Dimensions: 6.5 mm (0.25")
Mounting Hole PCD: 244 mm (9.6")
Number of Mounting Holes: 8
Chassis Depth (inc gasket): 73 mm (2.87")
Magnet Depth: 62 mm (2.43")
Overall Depth: 135 mm (5.3")
Unit Weight: 2.7 kg (6.0 lbs)
Springy, warm, revealing and highly expressive, it can be used singly or in pairs to add a classy sheen to any amp, or in a 4x10 configuration for higher volume depth, warmth and shimmer, with less of the boom associated with 4x12 cabinets.
Specifications
Nominal Diameter: 254 mm (10")Power Rating: 40W
Rated Impedance: 8Ω
Sensitivity: 98dB
Chassis Type: Pressed steel
Magnet Type: Alnico
Voice Coil Diameter: 1.75" (44.5 mm)
Voice Coil Material: Round copper
Frequency Range: 80-6000Hz
Resonance Frequency, Fs: 80Hz
DC Resistance, Re: 6.66Ω and 13.56Ω
Mounting Information
Cut-out Diameter: 229 mm (9")Diameter: 256 mm (10.1")
Magnet Structure Diameter: 119 mm (4.7")
Mounting Hole Dimensions: 6.5 mm (0.25")
Mounting Hole PCD: 244 mm (9.6")
Number of Mounting Holes: 8
Chassis Depth (inc gasket): 73 mm (2.87")
Magnet Depth: 62 mm (2.43")
Overall Depth: 135 mm (5.3")
Unit Weight: 2.7 kg (6.0 lbs)
