Make Noise QPAS Music Synthesizer Module

The Quad Peak Animation System music synthesizer module combines the auditory enveloping of stereo spaced peaks with the animation of two or more peaks in a single channel dancing around each other or engaging in primitive vocalizations. QPAS is Quad Core, containing four identical state variable filter cores with a control system powerful enough to guide them in stereo multi-peak operation, but simple enough to encourage system integration rather than domination.

Features

• Quad Core Stereo Analog
• Multi-Peak with clean resonance
• Fast response encourages deep FM
• Radiate spaces stereo image and animates associated channel
• High Q settings are under damped, excitable, and ring by gate or trigger
• 2 modulation inputs aid patch exploration
• Stereo VCA, pre-filter with gain
• Mono to Stereo, Stereo to Mono, Mono to Mono and Stereo to Stereo operations
• Smile Pass filter response unique to QPAS
• Low Pass, Band Pass, High Pass and Smile Pass outputs simultaneously available

Specifications

Width: 18hp
Max Depth (incl. power cable): 45mm
Power: 166mA@ +12V / 190mA @ -12V
