Audient iD24 10 in-14 out USB-C Audio Interface
Additional Photos:
Product Videos :
YouTube Video
Your Price: $549.00 CDN
or from $58 CDN/mo
Your recordings, made better.
Introducing iD24, the audio interface made for producers and engineers. Featuring two Audient Console Mic Preamps, class leading converters and an intuitive layout, iD24 effortlessly combines astonishing audio performance with ease of use. Add to that professional must have features like balanced inserts, ADAT expandability and customisable monitor control, iD24 makes getting studio quality results easier than ever.
Audient Console Mic Preamps
Every iD interface features the Audient Console Mic Preamp, the same discrete circuit design found in Audient's renowned recording console the ASP8024-HE. Designed to deliver ultra low noise and low distortion with a touch of classic analogue warmth, iD24's two Audient Console Mic Preamps deliver a clean, accurate and true to source translation of your audio.
The Audient Console Mic Preamp is a high grade hybrid discrete and op amp design that delivers a clean, accurate and detailed translation of your source. With a noise floor 30,000 times quieter than the signal level your recordings will be captured with stunning clarity.
Class Leading Converters
Hear every nuance, every aspect of your audio with iD24's class leading converters. With 32-bit DAC converter technology and 126dB of dynamic range, iD24s converters make sure you hear subtle details, identify problematic issues and make better mix decisions. Experience remarkable clarity from the moment you press play.
Digital I/O
Be ready to expand when you need to tackle bigger sessions like recording drums or a live band with iD24's optical input and output connections. Supporting both ADAT and SPDIF, iD24 lets you boost your I/O by adding up to 8 channels of mic preamps to your setup.
Balanced Inputs
Integrate your favourite outboard FX prior to conversion and start creating signal chains that rival the very best. The insert returns also gives you direct access to the A/D converters providing the cleanest signal path possible, making it great for print-backs or integrating outboard line level sources.
JFET Instrument Input
Designed to replicate the input stage of a classic valve amplifier, iD24's harmonically rich JFET Instrument Input gives you the perfect sonic foundation for your guitars or basses before you hit your amp sims.
USB Bus Powered
iD24 is fully bus powered via USB, meaning there is no need for an external power supply. Just pro features in a portable desktop package with zero compromise on sound quality or performance.
Headphones Output
Confidently reference check your mixes on headphones with iD24's independent stereo headphone amp, providing enough power to support headphones up to 600Ohms. And with both a 1/4" jack and a mini-jack, iD24 allows you to plug in two sets of headphones at once ensuring you and your artist can work together seamlessly.
Speaker Outputs
Connect and listen to your mixes through two sets of speakers with iD24's four line outputs. Alternatively use the extra line outputs to send audio to an external headphone amp for distribution to your artists.
User Defined Monitor Control
Speed up your workflow with iD24's three programmable function buttons. Assign any of the advanced monitoring features, including Speaker Select, Talkback, Polarity Invert or Mono Sum, to any of the F-buttons and quickly take control of your session.
The Virtual Scroll Wheel
Turn iD24's volume knob into a virtual scroll wheel and take control of a variety of compatible onscreen parameters. Quickly dial in settings, adjust faders or even write in automation without spending hours staring at the screen.
All Metal Construction
An all metal, smoke grey chassis alongside hand-milled aluminium knobs and high grade component selection means iD24 is designed to survive everyday use, whether at home on your desktop or up against the wear and tear of travel.
Features
• 2 x Class-A Audient Console Mic Preamps
• Class Leading AD/DA Converters
• 1 x Discrete JFET Instrument Input
• Main and Alt Speaker Outputs
• 1 x Independent Dual Headphone Output
• 1 x ADAT Input & Output
• 2 x Fully Balanced Inserts
• Ultra-low Latency DSP Mixer
• Audio Loop-back
• ScrollControl
• 3 x User Defined Function Keys
• Dedicated Dim and Cut Controls
• +48V, Pad, and HPF Switches
• USB 3.0 Compliant
• 24bit/96kHz
• Word Clock Output
• All-Metal Design
• Free Software + Plugins
Specifications
Microphone Preamplifier
Mic Gain: 0 to +58dB
Maximum Input Level: +12dBu
Crosstalk: 75dB@1kHz
SNR: 97.5dB Unweighted, 100dB A-Weighted
Frequency Response: +/- 0.5dB 10Hz to 40kHz
Input Impedance (Mic): 3kΩ balanced
Input Impedance (Line): 10kΩ balanced
PAD: -10dB
HPF Cutoff Frequency: 100Hz
Phantom Power: 48V +/-4V @ 10mA/Channel
XLR Combi Female XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4" TRS Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
Line Inputs
Line Rain: -10 to +48dB
Maximum Input Level: +22dBU
THD+N @0dBu 1kHz: 0.0013%, -97dB
D.I / Instrument Input
D.I Gain: 0 to 58dB
Maximum Input Level: +12 dBu
THD+N @ 0dBu (1kHz): 0.0075%, -82dB
SNR: 95dB unweighted, 97.5dB A-weighted
Frequency Response: +/- 0.5dB 0.5dB 10Hz to 40kHz
Input Impedance: 500kΩ unbalanced
1/4" Jack: Tip (Hot) & Sleeve (Shield)
Analogue to Digital Converter
Maximum Input Level: 12.5dBu=0dBFS
Crosstalk: @1k -135dB, @10k -125dB
Frequency Response: +/- 0.2dB 0.5dB 10Hz to Fs/2 (Nyquist)
THD+N @ -1dBFS (1kHz): 0.0004%, -108dB
Dynamic Range: 122dB A-weighted
Input Impedance: >10kΩ
1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)
Digital to Analogue Converter
Maximum Output Level: 12dBu=0dBFS
THD+N @ 1kHz -1dBFS: 0.0003%, -110dB
Dynamic Range: 126.5dB A-weighted
Crosstalk: -130dB @ 1kHz, -115dB @ 10kHz
Frequency Response: +/- 0.1dB 10Hz to Fs/2 (Nyquist)
Output Impedance: 100Ω
1/4" Jack: Tip (Hot), Ring (Cold) & Sleeve (Shield)
Headphone Outputs
Maximum Output Level: 18.5dBu=0dBFS
THD+N @ -1dBFS (1kHz): 0.0006%, -104dB
Dynamic Range: 124dB A-weighted
Crosstalk: -117dB @ 1kHz, -101dB @ 10kHz
Frequency Response: +/- 0.2dB 10Hz to Fs/2 (Nyquist)
Output Impedance: 50Ω unbalanced
Max Level Into 30R: 2.63V Peak, 1.87V RMS, 232mW
Max Level Into 60R: 4.28V Peak, 3.03V RMS, 295mW
Max Level Into 600R: 7.91V Peak, 5.6V RMS, 104mW
USB 2.0 High Speed
No. of Input Channels: 10 (2 Analogue, 8 Digital)
No. of Output Channels: 14 (6 Analogue, 8 Digital)
Connector: USB Type-C
Included Cables: 1m USB 2.0 Type-C to Type-C
Digital Input
8-Channel ADAT: 44.1kHz to 48kHz
4-Channel ADAT: 88.2kHz to 96kHz (SMUX)
Stereo S/PDIF: 44.1kHz to 96kHz (Stereo)
Digital Output
8-Channel ADAT: 44.1kHz to 48kHz
4-Channel ADAT: 88.2kHz to 96kHz (SMUX)
Stereo S/PDIF: 44.1kHz to 96kHz (Stereo)
DSP Mixer Latency
Round Trip (in-to-out)
44.1kHz: 0.344ms
48kHz: 0.312ms to 96kHz (SMUX)
88.2kHz: 0.188ms
96kHz: 0.177ms
Word Clock Output
Word Clock Output: 44.1kHz to 96kHz
