Pittsburgh Modular Taiga Paraphonic Modular Synthesizer
Additional Photos:
Product Videos :
Taiga oscillators
Waveforms generated by the three Taiga oscillators stretch beyond the basic geometric shapes and sounds associated with analog synthesis. Taiga waveforms pass through up to three proprietary, cascading waveshapers designed to precisely manipulate their symmetry and harmonic content. In addition, each oscillator includes a robust six-stage wave folder to add even more complexity and depth to the diverse sonic palate of Taiga.
The "Pittsburgh Filter"
The Pittsburgh filter has defined the sound of Pittsburgh Modular from the moment it was introduced. A signature gummy and relaxed sound with no dead spots that has been tweaked to perfection. It offers a warm, smooth sweep through the full frequency range and a sweet resonance that does not roll off the low end. This generation of the Pittsburgh filter is specifically designed to ensure a remarkable interplay with Taiga's oscillators.
Pittsburgh Dynamics Controller
Pittsburgh's new Dynamics technology imparts Taiga with a uniquely organic depth and presence. By simultaneously managing both amplitude and harmonic content, the Pittsburgh Dynamics Controller expands beyond the one-dimensional VCA found in other synthesizers. It does this by utilizing new advancements from traditional low pass gates to add additional definition and dimension to the voice of Taiga.
When used in low pass gate mode, sounds shed harmonic content and become warmer as they decrease in volume. This mimics how sound waves react to their environment. Because of this connection, the Taiga sounds more natural or complex compared to other instruments.
Analog Echoes
Echos is a beautifully dark analog delay tuned to enhance the source material by repeating it over and over. Echos utilize a pair of bucket brigade delay chips to produce a classic voltage-controllable analog delay effect that helps to place the sounds of Taiga in a simulated environment.
Open Architecture
Taiga has an internally defined signal path. Patch cables are not necessary to begin exploring. Attach a midi keyboard and plug the output into a speaker or DAW and Taiga is ready to go with a robust but familiar workflow. When your ideas grow beyond the pre-defined signal path, a 60 point patch bay opens up a fully modular instrument with access to an even deeper set of features and tools.
Complete Set of Modular Tools
Taiga includes a host of fully modular, analog, and digital synthesis tools to support and enhance its core functionality. Analog tools include a flexible dual mixer, a pair of plucky four-stage envelope generators, noise, and sample and hold. Digital tools cover external MIDI, arpeggiator, clock sync'd modulation tools, and a robust collection of random generators. The Taiga toolset is deep enough for any type of sonic exploration.
Taiga features
• Paraphonic synthesizer with unique additive elements
• Fully patchable - use Taiga's components as separate modules with external devices or reroute its internal patching.
• Controllable via MIDI, CV, and integrated pseudo random sequencing mode
• Clock-synced arpeggiator
• 3x Pittsburgh Modular Synthesizer developed 100% analog oscillators
• Oscillator waveforms - sine, triangle, and saw - Waveforms can be combined
• 3x Pittsburgh Modular Synthesizer 6 stage wave folder/shaper circuit - folds inputted waves back onto themselves to increase harmonic content
• Oscillators include frequency modulation (FM)
• Noise generator - pitched somewhere between pure white and pink noise. Perfect for percussion or adding a bit of edge to a sound.
• Variable state, multi-mode "Pittsburgh No-Dead-Spots" filter (lowpass, bandpass, highpass, modes can be combined)
• Sample & Hold circuit
• 2x Analog ADSR / envelope generators
• Pittsburgh dynamics section - an alternative to an envelope generator and a VCA, the dynamics controller is a Pittsburgh Modular invention that adds a dimension of control over a vactrol-less lowpass gate circuit, adding release time.
• Dual range analog LFO with square and triangle wave outputs.
• LFO Range High: 2 Hz to 500 Hz Low: 41 seconds to 5 Hz
• Dual Channel Mixer - 2 channel mixer and a 3 channel mixer joined together, capable of mixing both audio or control voltages.
• Preamp that uses a high gain, soft clipping overdrive limiter circuit to increase the level of audio signals. The preamp can be used to cleanly increase the level of external audio to internal signal levels, or it can be used as an overdrive / limiter for internal signals.
• Digital multi-mod tool - modulation control via CV, random generator, and extra LFO and envelope generator
• Internal clock with tap tempo and can be clocked via an external source.
• Built-in clock divider
• Echos - 100% analog bucket brigade delay
• Can be used standalone in its included case or removed and used as a eurorack format module
IN THE BOX:
- Taiga Paraphonic Modular Synthesizer
- Taiga wall-wart power supply
- (10) Amazing Nazca Noodles Patch Cables
- 3.5mm to 5 pin MIDI Din pigtail
Specifications for when used as a eurorack module
Width when used as a module = 60hp
Depth = 40mm
650mA power draw when running +12V rail
475mA power draw when running -12V
Input voltage range of oscillators = 0-10V
