American DJ Hydro Beam X1
Additional Photos:
Product Videos :
With robust construction and IP65-ratings, the Hydro Beam X1 is designed for both indoor or outdoor use. Its durable casing protects it from dust, sand, moisture and liquids, making it ideal for use in all situations from dusty deserts in California to rainy fields in England. Perfect for festivals and outdoor events, as well as installation in open-air clubs and other outside entertainment spaces, this groundbreaking fixture offer an extended operational life and reduced maintenance requirement due to their sealed casing design.
The Hydro Beam X1 has several high performance features such 16-facet circular prism with overlay and an independent frost filter for wash effects. Its fitted with 5-pin DMX In/Out and locking power In/Out connections. It offers a USB port for software updates. All connections are IP65 rated with rubber protective covers.
Features
• IP65 rated - protects from dust, sand, moisture, liquid
• Independent frost filter (wash effect)
• 0-100% smooth dimming
• Various strobe speeds
• Includes omega brackets
• Wifly EXR wireless DMX
• Antenna Range: 98.42ft (30m)
Specifications
Light Source
Lamp: Osram Sirius HRI 100W Long Life (6,000 hrs.) Discharge
Colour Temperature : 9000K
CRI: 60
Beam Angle: 3-degrees
Colour Wheel
12 colours + CTB & UV + open
GOBO Wheel
1 metal GOBO Wheel with 11 GOBOs, 4 GOBO reducers + open
Prism Wheel
16-facet circular prism (rotates in either direction)
Construction
Display: OLED display
Data In/Out: 5-pin DMX IP65 (with rubber protective covers over connections)
Power In/Out: locking IP65 (with rubber protective covers over connections)
Protection Rating: IP65
All metal case design
Control
2 DMX Channel Modes: 11/14 Channels
Control Mode: DMX512, RDM (Remote Device Management)
Firmware Upgrade: Update via IP65 USB port (with rubber protective covers over connections)
With Wired Digital Communication Network
Pan/Tilt
Pan/Tilt: 540/270
Electrical
Power voltage: AC100-240V, 50/60Hz (Multi-voltage)
Power linking: 6 units @ 120V; 12 units @ 240V
Power consumption: 235W max
Dimensions & Weight
Dimension: 13.2 x 8.3 x 16.9" (336 x 210 x 430 mm)
Weight: 36 lbs. (16.3 kg)
Operating Temperature
Minimum operating temperature: 14°F (-10C)
Maximum operating temperature: 113°F (45C)
Approvals
cETLus Approved (Control #4000358)
