American DJ Encore LP18IP
Additional Photos:
Product Videos :
The fixture's Quad LED engine offers flicker free operation for TV and film and linear white colour temperature control from 2700K - 7000K.
The Encore LP18IP unit is equipped with outdoor Locking Power connectors and IP rated 5-pin DMX rubber covers and connectors. IP rated power linking and DMX cables are available, but standard 5-pin DMX cables may also be used for indoor applications.
The Encore LP18IP includes a removable 25-degree frost filter. There are several additional frost filter options (sold separately) that customise the beam angle. All filter snap into the front of the fixture.
Features
• 6 DMX modes
• 5 operational modes
• 6 selectable dimming modes
• 4 selectable dimming curves
• 4-Button DMX menu with digital display
Specifications
Source
Light Source: 18 x 20-Watt Quad RGBL LEDs (4-IN-1: Red, Green, Blue & Lime)
Photmetric Data
Beam angle: 10° (includes 25° removable frost filter)
CRI: 86.2
CRI R9: 82.8
Lumens: 7300
Effects
Linear Colour Temperature Control (2700K to 7000K)
Preset Colour Temperatures (2700K, 3200K, 4000K, 5600K and 6500K)
16-Bit Fine Colour Control (Red, Green, Blue & Lime)
64 built-in Colour Macros
Control/Connections
4-button, DMX digital display on rear panel
5 Operational modes: Static Colour Mode, RGBL Dimmer Mode, Program Mode, Sound Active Mode and DMX Controlled
Supports RDM (Remote Device Management)
With Wired Digital Communication Network
6 selectable Dimming Modes (Standard, Stage, TV, Architectural, Theatre & Stage 2)
4 selectable Dim Curves (Linear, Square Inv. Squa, S-Curve)
Adjustable Refresh Rate (14 presets from 900 - 25,000Hz)
Flicker Free operation (No flickering on camera)
LED pulse and strobe effect
Electronic Dimming: 0 - 100%
6 DMX Modes: 4, 7, 8, 10, 13, & 16-channel
Quiet fan mode
Construction
IP65 Rated: Ingress Protection against liquid, snow, dust and sand
All metal construction
IP Rated rubber covers protect In/Out Locking Power connectors and IP rated 5-pin sockets
Locking, outdoor IN/OUT Power connectors
Data linkable via 5-pin XLR DMX connections
Scissor Yoke & safety eye
Electrical/Thermal
Multi-voltage operation: AC 100-240V, 47/63Hz
Daisy chain: 2 @ 120V, 6 @ 220V
Max power: 240W
Dimensions/Weight
Dimensions: 11.85 x 9.25 x 11.5" (300 x 234 x 289 mm)
Weight: 16 lbs (7.15 kg)
Approvals/Ratings
cETLus Pending
IP65
Included Accessories
- 25° Frost Filter
- Power Cord
Media
