Flock Audio Patch XT 96-In/96-Out Digitally Controlled Analog Patchbay
Additional Photos:
Product Videos :
PATCH XT - Extra Extraordinary
The highly anticipated and long awaited PATCH XT System harnesses the advanced analog routing technology of the PATCH Series of products in a mammoth I/O configuration of 192 Points (96 Inputs / 96 Outputs). Meticulously designed, the PATCH XT System was created for power users who need to get the most of out of their analog hardware routings capabilities. Equipped with the same Patented Matrix Technology as Flock Audio's flagship model PATCH, the XT System boasts some sought after upgrades including Locking USB Host Connector, CAT5 Ethernet Network Host Connector option, Beautifully machined anodize panel among many other upgrades.Features
• 96-IN / 96-OUT Analogue Connections
• One Switch, One Multi Purpose LED Indicator
• Locking USB Connector
• Additional CAT5 Network Connection Included
• Front IO Access
• Redesigned Airflow for Superior Cooling
• Built In IEC Power Supply
In the Box
• PATCH - (3U Hardware Rack Unit) Dimensions: 19" (W) x 5.25" (H) x 12" (D)
• USB 2.0 - (6 ft) Host Control Cable (USB-A to USB-B) w/ Locking USB Connection
• Power Supply - Internal Power (110V or 220V) Power Supply
• Power IEC Cable - (Shipped with IEC Plug based upon customer region)
• 6 Step Quick Start Setup Guide
• Hardware Index Setup Template
Specifications
Computer Connectivity: USB 2.0
Compatibility: OSX 10.7 Lion & Newer / Windows 7 & Newer
Software: PATCH APP v2.0, Online Download (iOS iPad Coming Soon)
Chassis: 3U Rackmount (13" Deep)
Patch Point Connections: 192 Total - 96 Inputs / 96 Outputs (Expandable with all PATCH Models)
48v Phantom Power: 32 Channels Independently Controllable
Front Connectors: 2x Combo TRS/XLR Inputs & 2x XLR Outputs
D/A or A/D Conversion: No AD/DA Conversion, 100% Analog, Sonically Transparent Audio Path
Routing System: Patended Flock Audio Matrix Technology
Analog Connections: DB-25/D-SUB Female Connectors (Standard Tascam Wiring Pinout)
*Special Order Product: Due to supply, this product is available by special order only. Contact your local Long & McQuade or Web Sales Representative for more information.
