Tascam Mixcast 4 Podcast Station Recorder/USB Audio Interface
Additional Photos:
Product Videos :
YouTube Video
YouTube Video
YouTube Video
Your Price: $599.00 CDN
or from $63 CDN/mo
Podcast Audio Creation Made Easy
Mixcast 4 makes professional content creation easy. For Podcast creation, live streaming, event production, or voice over, Mixcast 4 will mix and record mic inputs, internal sounds and music via the trigger pads, and external audio input from your phone or PC. Together with the TASCAM Podcast Editor software, a complete solution - including both waveform editing and sound pad control - is provided from pre-production to completion.
Improve your production workflow and inspiration
The Mixcast 4 is a one-stop workstation that allows for the recording and mixing of sound sources without complicated settings. It provides all audio-related operation and workflow needed for live-streaming, events, podcasts, and other applications. The bundled TASCAM Podcast Editor software will expand the ability to assign content and sound effects to the internal touchpads, and will allow for smooth and easy remote track arming, effects assignment, audio editing and more without the need for expertise and complexity.
Features
• Podcast production of up to 4 people: 4 mic inputs with auto-mix, 4 headphone outputs
• Invite guests and friends: Mix-Minus to connect call-ins with echo-free audio via Bluetooth, USB input or 4-pole TRRS audio cable
• Sound pads for instant sound triggering and effects
• Easy and intuitive control using the 5-inch touch panel
• Fully compatible with the dedicated TASCAM Podcast Editor software to cover the entire production workflow
• Direct internal multi-track recording to SD card (up to 14 tracks)
• 14in/2out USB audio interface
• Includes power adapter and USB Type-C to Type-C cable
Specifications
Recording media: SD cards (64 MB to 2 GB), SDHC cards (4 GB to 32 GB), SDXC cards (48 GB to 512 GB)
MIC INPUT jacks (1-4):
Connectors: XLR/TRS combo jacks
XLR: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
TRS: 6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)
LINE IN (TRRS) jack (CTIA standard):
Connector: 3.5 mm (1/8") 4-pole mini jack
Analog audio output ratings:
PHONES jacks (1-4)
Connectors: 6.3mm (1/4") standard stereo jacks
Maximum output: 45 mW + 45 mW (0.1% THD+N or less, into 32Ω load)
PHONES (TRRS) 1 jack (CTIA standard)
Connector: 3.5 mm (1/8") 4-pole mini jack
PHONES (TRRS) 1 output splits from PHONES 1 output
LINE OUT (TRRS) jack (CTIA standard)
Connector: 3.5 mm (1/8") 4-pole mini jack
MONITOR OUT L/R (balanced) jacks
Connectors: 6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)
LINE OUT jack:
Connector: 3.5mm (1/8") stereo mini jack
Control input/output
Connector: USB Type-C
Formats: USB2.0 HIGH SPEED
USB AUDIO CLASS 2.0
USB MASS STORAGE CLASS
Bluetooth
Output class: 2 (about 10m unobstructed transmission distance)
Supported profile: A2DP
Recording times (in hours: minutes): Recording format: 24-bit / 48kHz WAV
14 ch: 0:35 (4 GB) / 1:10 (8 GB)
2 ch: 4:07 (4 GB) / 8:15 (8 GB)
Power consumption: 12.5 W (maximum)
Weight: 2.55 kg
Dimensions: 374.8 71.2 266.7 mm
Include items: AC adapter (PS-1220E NUT), USB Type-C to Type-C cable, Owner's manual
Supported OS'
• Windows 10 (May 2021 Update) New
• MacOS Big Sur , macOS Catalina
• iPadOS 14 , iOS 14 , iPadOS 13 , iOS 13
Mixcast 4 makes professional content creation easy. For Podcast creation, live streaming, event production, or voice over, Mixcast 4 will mix and record mic inputs, internal sounds and music via the trigger pads, and external audio input from your phone or PC. Together with the TASCAM Podcast Editor software, a complete solution - including both waveform editing and sound pad control - is provided from pre-production to completion.
Improve your production workflow and inspiration
The Mixcast 4 is a one-stop workstation that allows for the recording and mixing of sound sources without complicated settings. It provides all audio-related operation and workflow needed for live-streaming, events, podcasts, and other applications. The bundled TASCAM Podcast Editor software will expand the ability to assign content and sound effects to the internal touchpads, and will allow for smooth and easy remote track arming, effects assignment, audio editing and more without the need for expertise and complexity.
Features
• Podcast production of up to 4 people: 4 mic inputs with auto-mix, 4 headphone outputs
• Invite guests and friends: Mix-Minus to connect call-ins with echo-free audio via Bluetooth, USB input or 4-pole TRRS audio cable
• Sound pads for instant sound triggering and effects
• Easy and intuitive control using the 5-inch touch panel
• Fully compatible with the dedicated TASCAM Podcast Editor software to cover the entire production workflow
• Direct internal multi-track recording to SD card (up to 14 tracks)
• 14in/2out USB audio interface
• Includes power adapter and USB Type-C to Type-C cable
Specifications
Recording media: SD cards (64 MB to 2 GB), SDHC cards (4 GB to 32 GB), SDXC cards (48 GB to 512 GB)
MIC INPUT jacks (1-4):
Connectors: XLR/TRS combo jacks
XLR: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
TRS: 6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)
LINE IN (TRRS) jack (CTIA standard):
Connector: 3.5 mm (1/8") 4-pole mini jack
Analog audio output ratings:
PHONES jacks (1-4)
Connectors: 6.3mm (1/4") standard stereo jacks
Maximum output: 45 mW + 45 mW (0.1% THD+N or less, into 32Ω load)
PHONES (TRRS) 1 jack (CTIA standard)
Connector: 3.5 mm (1/8") 4-pole mini jack
PHONES (TRRS) 1 output splits from PHONES 1 output
LINE OUT (TRRS) jack (CTIA standard)
Connector: 3.5 mm (1/8") 4-pole mini jack
MONITOR OUT L/R (balanced) jacks
Connectors: 6.3mm (1/4") standard TRS jacks (Tip: HOT, Ring: COLD, Sleeve: GND)
LINE OUT jack:
Connector: 3.5mm (1/8") stereo mini jack
Control input/output
Connector: USB Type-C
Formats: USB2.0 HIGH SPEED
USB AUDIO CLASS 2.0
USB MASS STORAGE CLASS
Bluetooth
Output class: 2 (about 10m unobstructed transmission distance)
Supported profile: A2DP
Recording times (in hours: minutes): Recording format: 24-bit / 48kHz WAV
14 ch: 0:35 (4 GB) / 1:10 (8 GB)
2 ch: 4:07 (4 GB) / 8:15 (8 GB)
Power consumption: 12.5 W (maximum)
Weight: 2.55 kg
Dimensions: 374.8 71.2 266.7 mm
Include items: AC adapter (PS-1220E NUT), USB Type-C to Type-C cable, Owner's manual
Supported OS'
• Windows 10 (May 2021 Update) New
• MacOS Big Sur , macOS Catalina
• iPadOS 14 , iOS 14 , iPadOS 13 , iOS 13
Media
Youtube video product demo
Youtube video product demo
Youtube video product demo
Q & A
There are currently no questions for this product.
Reviews
18.118.226.246
Mozilla/5.0 AppleWebKit/537.36 (KHTML, like Gecko; compatible; ClaudeBot/1.0; [email protected])
A Brilliant Mixer / Interface 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store White Rock, British Columbia
I recently bought both the Rodecaster Pro II and This Mixcast 4 to determine which was best suited for my use case. Both are outstanding devices but I actually preferred the Mixcast 4. Why? It's by far more intuitive to use and to set up and all of the channels and sound pads are labelled so you dont have to memorize 64 sound effects. The PreAmps on both are super clean and the build quality is solid. One of the things I really appreciated on the Tascam was both Balanced 1/4" monitor outputs and a 3.5mm unbalanced. This for me anyway is a big deal because I use this device as a USB audio interface and my computer monitor speaker is TV Soundbar that only take optical or 3.5 input. On every other interface I've used (including the Rodecaster) that only has balanced outputs, this is a problem because it produces all kinds of hum and noise into the unbalanced input. It was the same issue with Bose Computer Monitor speakers with RCA inputs. My Motu M4 interface has balanced and unbalanced outputs and its flawless and now, so too does this MIXCAST 4. Thank You Tascam. The only and biggest shortcoming with the MIXACST and The Rode is that it is impossible to toggle off channel or mic monitoring from monitor or headphone outputs. This is a problem because if you're like me who lives on Zoom, Team and other confencing apps. the monitoring creates all kinds of mic feedback. As I said to to both Rode and Tascam in customer service exchanges - virtually every USB Interface has the ability take the mic out of the monitor mix so you can receive the PC / USB audio without feedback. They claimed "Well this is a mixer" to which I replied "No, It's an interface and a mixer" Rode apparently has now released a beta firmware to toggle off Mic Monitoring. I've asked Tascam to do the same as a feature request.- Let's see what happens. Lastly I want to commend Tascam for their outstanding customer support. When I was setting the thing up I had a question. I called their californina number, left a message and had a call back to trouble-shoot 15 minutes later. That's impressive. My final comment would be this. By all accounts the Rodecaster Pro II is a more accomplished Poscast Studio. It provides more gain in the Mic Pre-Amps and has more functions. But for a guy like me, who just needs and wants a compressor and noise gate, multiple mic inputs and interface combined, The MIXCAST is the perfect device. The Rode is an F-18 with all the complexity of an F-18, the Mixcast is a smooth efficient Leerjet.
Posted by Howard O on Jan 23, 2023
Quality is Lacking 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Toronto (LM Pro), Ontario
Bought it early November 21, it was great. Dead early February 22. Been at L&M for the past month for repair.
Posted by Ken MacDougall on Mar 22, 2022
Rivals the Rodecaster Pro 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store North Vancouver, British Columbia
Having thoroughly tested and compared the Rodecaster to the Tascam Mixcast, the build quality difference alone is vastly noticeable. The rigidity of the chassis and quality feel of the faders feels professional, whereas the Rodecaster feels like a cheap plastic toy.
One of the most important features is sound quality. The Mixcast has 10dB more gain on the preamps (66dB to be exact). They sound great and are transparent, allowing you to get gain hungry mics like the SM7B or RE20 up to a reasonable level without an inline preamp (such as the Cloudlifter).
The touchscreen is nice and larger than on the Rodecaster, which I like. Feature for feature it is almost neck and neck with the Rodecaster, featuring dynamics processing on all channels. A big firmware update is coming this month (Feb 2022) that will add some missing features such as auto mute studio monitors when microphones are on, a rather important feature found on expensive broadcast consoles.
The I/O is expansive and more robust than the Rodecaster. The first four mic inputs are combo jacks that allow XLR or 1/4" line level, unlike the Rodecaster. You will also find an additional balanced stereo 1/4" line level input if you want to insert additional outboard gear, something the Rodecaster does not have.
One of the most important features is sound quality. The Mixcast has 10dB more gain on the preamps (66dB to be exact). They sound great and are transparent, allowing you to get gain hungry mics like the SM7B or RE20 up to a reasonable level without an inline preamp (such as the Cloudlifter).
The touchscreen is nice and larger than on the Rodecaster, which I like. Feature for feature it is almost neck and neck with the Rodecaster, featuring dynamics processing on all channels. A big firmware update is coming this month (Feb 2022) that will add some missing features such as auto mute studio monitors when microphones are on, a rather important feature found on expensive broadcast consoles.
The I/O is expansive and more robust than the Rodecaster. The first four mic inputs are combo jacks that allow XLR or 1/4" line level, unlike the Rodecaster. You will also find an additional balanced stereo 1/4" line level input if you want to insert additional outboard gear, something the Rodecaster does not have.
Posted by Alex Knight on Feb 2, 2022
