Native Instruments Traktor Kontrol Z1 Controller

TRAKTOR KONTROL Z1 is the ultra-compact 2-channel mixer, controller, and soundcard for TRAKTOR DJ and TRAKTOR PRO 2.

Little Giant
TRAKTOR KONTROL Z1 is the ultra-portable, professional DJ mixing controller forTRAKTOR DJ andTRAKTOR PRO 2. Its cue section lets you monitor and mix tracks with pro precision. Dedicated controls for two channels give you intuitive, tactile control over volume, EQ, filters, and effects. And the built-in audio interface delivers powerful, club-ready sound.

Get total control and professional sound in a go-anywhere package its pro on the go.

Perfect Combo
Want to deliver floor-shaking DJ sets with TRAKTOR DJ? Connect your iPad or iPhone to the Z1 and get a complete two-deck DJ setup with ultimate tactile control. Cue up the next track in your headphones while the current track still plays for the crowd. Mix and EQ with pro-grade faders, knobs, and buttons. Apply filters and effects with the ultra-intuitive one sweep knob.

The Z1 even switches your turned-on iOS device to external power while you play, so you never have to worry about battery life when your set hits its peak.

Club Compact
TRAKTOR KONTROL Z1 works perfectly with TRAKTOR PRO 2 plug in and instantly start mixing with hands-on control and premium, club-ready sound. You can also expand your mobile rig with additional creative possibilities: Add TRAKTOR KONTROL X1 to control effects, loops and transport functions like play and sync, and TRAKTOR KONTROL F1 for creative Remix Deck magic.

Whatever your style, build your setup around TRAKTOR KONTROL Z1 and rock the club or the after-party with the most compact, portable TRAKTOR system ever.

E-Voucher Included
TRAKTOR KONTROL Z1 also includes an e-voucher• worth $50, valid towards the purchase of any downloadable software at the NI Online Shop exclusively. Expand your sonic arsenal!

EQ AND FILTER SECTION
With a 3-band EQ, dedicated gain controls, and chunky filter knobs for each of its two channels, the top section of TRAKTOR KONTROL Z1 gives you full tactile control over your DJ sets. When using TRAKTOR DJ, pressing and holding the Mode button independently toggles decks between filter (button turns blue) and one-knob FX control (button turns orange). When using TRAKTOR PRO 2, the Mode button toggles between low- and high-resonance filters.

CUE SECTION
Use the A and B buttons to select which channel you want to cue. The Cue Mix knob adjusts the ratio between cue signal and master output in your headphones. Cue Volume adjusts headphone cue volume.

FADER SECTION
With smooth line faders for both decks as well as a crossfader, TRAKTOR KONTROL Z1s fader section lets you mix with effortless style. The easy-to-read level meters give you instant visual feedback when rocking the club.

HARDWARE SPECIFICATIONS

Overall
Sampling rate: 96kHz
Converter wordlength: 24-bit
Analog output channels: 4
USB audio interface: USB 2.0 hi-speed, audio class compliant

Master RCA outputs
Maximum output level (unbalanced): +12.5 dBu
Noise floor: -89,3 dB a weighted
Dynamic range: +101.5 dB a weighted
THD+N: 0.003% (LP 20kHz)
Frequency response: 20-40000Hz, +/- 0.1 dB
Crosstalk: -116 dB

Headphone output
Maximum output level: 12.3 dBu/ 3,2 Vrms (100K load)
Maximum output power: 40 mW
THD+N: 0.004% (100K load)
Noise floor: -94 dBu
Dynamic range: 101 dB
Frequency response: 20-40000Hz, +/- 0.1 dB
Crosstalk: -82 dB (100K load)

SYSTEM REQUIREMENTS
Windows 7 or 8 (latest Service Pack, 32/64 Bit), 2.0 GHz Intel Core 2 Duo or AMD Athlon 64 X2, 2 GB RAM (4 GB recommended)

Mac OS X 10.7 or 10.8 (latest update), Intel Core 2 Duo, 2 GB RAM (4 GB recommended)
General: Monitor with 1024 x 768 screen resolution, USB 2.0, 1 GB free disc space, high-speed internet required

TRAKTOR DJ SYSTEM REQUIREMENTS
iPad version: iOS 6 or higher, iPad 2 or later, or iPad mini

iPhone version: iPhone 4 / iPod 4th generation or later. 500 MB free storage/disk space on your iOS device is recommended.
