Audient EVO 8 4-In/4-Out Audio Interface
Additional Photos:
Product Videos :
Key Features
• 4x EVO Preamps - Get the most from your microphones with the warm and accurate EVO preamps offering 58dB of gain range.
• Class Leading AKM Converters (AD/DA) - Hear your recordings more accurately than ever and make better mix decisions with 113dB of dynamic range.
• Smartgain - Dial in your channels automatically
• JFET Instrument Input - Plug your guitar or bass straight in through the JFET instrument input and start recording instantly.
• Smart Touchpoints - Control your speakers, headphones and channels all using the volume encoder
• 2 x Stereo Speaker Outputs - Plug in two sets of speakers
• 2 x Headphone Outputs - High performance headphone outputs
• Low Latency Software Mixer - Designed to simplify and adapt to your workflow
• Audio Loop-back - Audio Loop-back enables you to record your computer audio at the same time as your microphones. Ideal for podcasters and streamers.
• USB2.0 Bus Powered - Power from your computer
• Phantom Power - True switchable +48V over Bus Power
• Free Software + Plugins - All you need to start
Smartgain Mode - Work smarter not harder
Make sure you capture everything perfectly with Smartgain mode. Start playing or singing and Smartgain mode will automatically set the level of your microphones. You can even perfectly match and adjust gain to all channels simultaneously.
Customisable Software Mixer
Designed to simplify and adapt to your workflow, the EVO Mixer enables you to effortlessly set up and route your inputs + outputs, provide ultra-low latency monitoring, balance and set your levels, activate phantom power, set up dedicated artist headphone mixes and more.
Free software
Compatible with all major audio software and plugins, EVO 8 comes bundled with a collection of professional software, giving you everything you need to start recording.
Specifications
Microphone Preamplifier
Mic Gain Range: 58dB
Line Gain Range: 58dB (-10dB pad)
Phantom Power: 48V +/-4V @ 10mA/Channel (only 2 channel available on USB-A host computers
Mic EIN: < -128dBu
CMRR: > 85dB @ 1kHz
Maximum Input Level: +16dBu
Input Impedance (Mic): >3kΩ Balanced
Input Impedance (Line): > 10kΩ Balanced
Frequency Response: +/-0.5dB 10Hz to 40kHz
Crosstalk: < -105dBu @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz): < 0.0015%
SNR: 100dB
XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
ADC Inputs
Digital Reference Level: 0dBFS = +8dBu
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -105dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz): < 0.001%
Dynamic Range: 113dB A-weighted
DAC Outputs
Maximum Output Level: +11dBu
Digital Reference Level: 0dBFS = +11dBu
Output Impedance: < 100Ω Balanced
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: < -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): < 0.0015%
Dynamic Range: 113dB A-weighted
Headphone Output
Output Impedance: < 50Ω
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): < 0.0015%
Dynamic Range: 113dB A-weighted
USB 2.0 High Speed
No. Of Input Channels: 24 Analogue
No. Of Output Channels: 4 Digital
Connector: USB Type-C
Included Cables: 1m USB 2.0 Type-C to USB Type-C
Weight & Dimensions
Weights: 0.475kg
Dimensions: 190mm (w) x 70mm (h) x 70mm (d)
Media
Q & A
Reviews
When doing some vocal recording with a modest condenser mic, the quality is good (I’m just a hobbyist, not pro), and again the smart gain feature is useful. If u don’t like the smart gain, u can dial in manually with ease. I get good sound quality thru headphones as well.
The design makes this very easy to use.
Negatives- powered only by usb-c. If using with iPad, cannot use the Evo mixer (I have contacted mfr, they have no plans to change this). Also, the Evo 8 is technically not supported by iPad (even tho it works with no issues), and unlike the Evo 4, you do not get a code for Cubasis LE (IOS). Unit is plastic, but is sturdy enough, just don’t drop it.
Overall, I think anybody wud be happy with this unit, probably even more so if used with a laptop. Hard pressed to find a quality 4in/4out interface at this price.
