Yorkville Sound 2 x 850 Watt Power Amplifier
Additional Photos:
Your Price: $769.00 CDN
or from $81 CDN/mo
Perfect for club or concert hall, the Yorkville PX Series PX1700 power amplifier delivers up to 1700 watts (2 x 850 watts @ 2 ohms). XLR and 1/4-inch inputs, binding post and Speakon outputs ensure the PX1700 can be integrated into virtually any high performance sound system or mobile PA.
Proven Class-H amplifier topography provides wide frequency response, extremely low self-noise and low harmonic distortion making Yorkville PX Series amplifiers some of the best performing audio amplifiers in their class. Built for maximum versatility, all PX Series amplifiers have XLR and -inch inputs, Speakon and binding post outputs and defeatable limiter.
Compact two rack space design, solid steel chassis and highly efficient front to back fan cooling scheme so typical road case or rack installation won't impede airflow ensures long-term reliability in any touring system or audio install application.
Features:
• Easily Drives Reactive Loads
• Delivers1700 Watts Bridged Mono @ 4 ohms
• 850 Watts pre Channel @ 2 ohms
• Efficient Front-to-Back Cooling Scheme
• Recessed Front Panel Gain Controls
• Advanced Protection Schemes
• Front Panel Power, Protect, Activity and Clip LED's
• Speakon and Binding Post Outputs
• Balanced XLR & -inch TRS Inputs
• Sturdy All-Steel Construction
Specifications:
• Amplifier class: Class-H
• Continuous Average Power @ 8 Ohms BCD (Watts): 400
• Continuous Average Power @ 4 Ohms BCD (Watts): 600
• Continuous Average Power @ 2 Ohms BCD (Watts): 850
• Continuous Average Power Bridged BCD (Watts): 1700
• Burst Average Power @ 8 Ohms BCD(Watts): 600
• Burst Average Power @ 4 Ohms BCD (Watts): 1000
• Burst Average Power @ 2 Ohms BCD (Watts): 850
• Burst Average Power Bridged BCD (Watts): 1700
• Frequency Response (Hz, +/- 1dB): 30Hz to 20kHz
• Hum and Noise (un / Aweighted -dB): -100dB
• THD -1kHz- 4 OHMS: 0.0003
• THD - 20Hz-20kHz, 4 Ohms: 0.001
• Damping Factor (30 Hz - 400 Hz @ 8 Ohms): Greater than 300
• Crosstalk (1kHz / 20Hz-20kHz): -75dB / -60dB
• Input Impedance - Bal/Unbal (Ohms): 30kOhms/15kOhms
• Input Sensitivity (Vrms) For Full Power Out: 1.4
• Max Voltage Gain (dB): 31dB
• Stereo / Mono / Bridge )S/M/B): Yes
• Protection: DC/Load/Thermal
• Limiter: Defeatable
• High Pass Filter: No
• Cooling: Fan
• Cooling Path: Front to Back
• Inputs - XLR: Yes (x2)
• Inputs - 1/4 IN Jacks: Yes (x2)
• Outputs - Speakon 4-pin: Yes
• Outputs - Binding Post: Yes
• Power Consumption (typ/max): 700/1500
• Rack Spaces: Two
• Transformer Type: Toroidal
• Exterior Finish: Black Paint
• Dimensions (DWH /D fm ears, inches): 16 x 19 x 3.5
• Dimensions (DWH /D fm ears, cm): 40.6 x 48.3 x 8.9
• Weight (lbs / kg): 35/16
Proven Class-H amplifier topography provides wide frequency response, extremely low self-noise and low harmonic distortion making Yorkville PX Series amplifiers some of the best performing audio amplifiers in their class. Built for maximum versatility, all PX Series amplifiers have XLR and -inch inputs, Speakon and binding post outputs and defeatable limiter.
Compact two rack space design, solid steel chassis and highly efficient front to back fan cooling scheme so typical road case or rack installation won't impede airflow ensures long-term reliability in any touring system or audio install application.
Features:
• Easily Drives Reactive Loads
• Delivers1700 Watts Bridged Mono @ 4 ohms
• 850 Watts pre Channel @ 2 ohms
• Efficient Front-to-Back Cooling Scheme
• Recessed Front Panel Gain Controls
• Advanced Protection Schemes
• Front Panel Power, Protect, Activity and Clip LED's
• Speakon and Binding Post Outputs
• Balanced XLR & -inch TRS Inputs
• Sturdy All-Steel Construction
Specifications:
• Amplifier class: Class-H
• Continuous Average Power @ 8 Ohms BCD (Watts): 400
• Continuous Average Power @ 4 Ohms BCD (Watts): 600
• Continuous Average Power @ 2 Ohms BCD (Watts): 850
• Continuous Average Power Bridged BCD (Watts): 1700
• Burst Average Power @ 8 Ohms BCD(Watts): 600
• Burst Average Power @ 4 Ohms BCD (Watts): 1000
• Burst Average Power @ 2 Ohms BCD (Watts): 850
• Burst Average Power Bridged BCD (Watts): 1700
• Frequency Response (Hz, +/- 1dB): 30Hz to 20kHz
• Hum and Noise (un / Aweighted -dB): -100dB
• THD -1kHz- 4 OHMS: 0.0003
• THD - 20Hz-20kHz, 4 Ohms: 0.001
• Damping Factor (30 Hz - 400 Hz @ 8 Ohms): Greater than 300
• Crosstalk (1kHz / 20Hz-20kHz): -75dB / -60dB
• Input Impedance - Bal/Unbal (Ohms): 30kOhms/15kOhms
• Input Sensitivity (Vrms) For Full Power Out: 1.4
• Max Voltage Gain (dB): 31dB
• Stereo / Mono / Bridge )S/M/B): Yes
• Protection: DC/Load/Thermal
• Limiter: Defeatable
• High Pass Filter: No
• Cooling: Fan
• Cooling Path: Front to Back
• Inputs - XLR: Yes (x2)
• Inputs - 1/4 IN Jacks: Yes (x2)
• Outputs - Speakon 4-pin: Yes
• Outputs - Binding Post: Yes
• Power Consumption (typ/max): 700/1500
• Rack Spaces: Two
• Transformer Type: Toroidal
• Exterior Finish: Black Paint
• Dimensions (DWH /D fm ears, inches): 16 x 19 x 3.5
• Dimensions (DWH /D fm ears, cm): 40.6 x 48.3 x 8.9
• Weight (lbs / kg): 35/16
Q & A
There are currently no questions for this product.
Reviews
18.217.14.208
Mozilla/5.0 AppleWebKit/537.36 (KHTML, like Gecko; compatible; ClaudeBot/1.0; [email protected])
Fantastic Amplifier 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Pickering (Store), Ontario
I bought this amplifier primarily to drive a subwoofer, and it delivers powerful, clean bass right down to 30Hz. I've occasionally used it to run FOH and it's excellent - low distortion and very forgiving.
I've been so impressed with it I've recently bought another one. Great, versatile, dependable little amp.
I've been so impressed with it I've recently bought another one. Great, versatile, dependable little amp.
Posted by Andre B on Feb 15, 2022
Good value for your dollar 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Winnipeg (Henderson), Manitoba
This amp brought a new meaning to my Cerwin Vega's Intense 252. It reminded me why i bought the Cerwin Vega's. The highs,mids and the lows that this amp produces is incredible. THAT'S WHY THIS AMP IS A GOOD VALUE FOR YOUR DOLLAR. THE DOLLAR JUST KEEPS ON GOING.
Posted by Rick on Sep 26, 2021
Great Basic Power 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store St. John's, Newfoundland and Labrador
I have owned one of these for over 10 years and it is rock solid. It is clean, gets down to 30 hz, and can put it out all night long. Great for anyone who is on a budget and looking for quality sound and power.
The only quibble I have is that it while it has speakon and binding posts outputs, there are no 1/4 inch outputs, I had to junk off the ends of two of my speaker cords to hook it up lol. If you use speakon cords, it don't matter and for the quality and power you are getting, its worth the sacrifice of a few 1/4 speaker cords if you don't have speakons.
Posted by anonymous on Nov 4, 2019
Amazing Amplifier 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Hamilton, Ontario
Sounds fantastic, amazing clean output power, and amazing price. What more can I say. Oh and it even has a built in limiter.
Posted by Josh on Jan 5, 2019
What an amp! 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Burlington, Ontario
I use this amp for my bass rig. I bridge it into mono and run a Traynor 4x10-4 Ohm version. So by the specs I'm pushing 1700 watts into it. Probably closer to 1100 but man, it sounds great and has never failed! It is heavy though, but most good stuff is.
Posted by anonymous on Jan 11, 2016
Great Amp 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store St. John's, Newfoundland and Labrador
Clean, powerful, quiet, goes down to 2 ohms, built in speaker protection, awesome value. Its a great amp.
Just one little quibble, it don't have 1/4 output jacks, just speakon and posts.
Posted by David Benson on Sep 2, 2015
Good Amp 1 of 1 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Vancouver, British Columbia
just got one to replace my old AP1020 series amp with noisy fan.this amp is really impress me with clean power,good sound quality and good quality built....Thanks Yorkville for your hard work...the only think i dont like is that the product not made in canada...it assemble in China....
Posted by JOhn on Apr 28, 2015
Yorkville PX1700 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Victoria, British Columbia
i bought the PX1700 amp to power my Yorkville Elite12 speakers. The Amp provides very clean,detailed and transparent power for what ever is played through it. i listen to jazz,blues, and some classic rock vinyl played through a Stanton st.150 Turntable and a SM ProM2 patch passive preamplifier its a winning combination and a incredible value i love the Yorkville build quality.Thank you Yorkville!
Posted by jason heatley on Jul 29, 2014
Great little Amp 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Winnipeg (Pembina), Manitoba
Great sounding Amplifier for the money, Powers two E12's. Don't let the price fool you.. this is a good one..!
Posted by Brian on Jan 8, 2014
N/A 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Abbotsford, British Columbia
Great Amp for the money, Decent Power, Good quality sound, Works good with Yorkville E12 Speakers.
Posted by anonymous on Jan 1, 2014
N/A 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Ottawa, Ontario
I've only had this about 3 weeks, so far so good, does what it's suppose to do...can't complain about that...very heavy amp so don't think your gonna haul it around...good value for money...
Posted by Davejc on Nov 6, 2013
FOH Audio Tech - Product Highly Recommended 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Pickering (Store), Ontario
I currently use this amplifier for my subs in my living room, i occasionally pull the amp out of the rack for the odd show. - Its rugged design and low distortion specs (It beats most QSC & Crown Amps!) make the speakers more efficient and can take more of a beating (the amp). Also, if you Bridge the amplifier, a single 15Amp outlet can run it, which doesnt leave you stressing for a bigger receptacle that isn't found in most venues. I will definitely purchase a few more of these. Maybe as monitor amps?
Posted by Will E on Jun 22, 2013
great amp 2 of 2 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Winnipeg (Pembina), Manitoba
bought this for my magnaplanar speakers, since they are @ 4 ohms amps provide enough power.
Posted by john on May 11, 2013
This is how it was suppose to be 4 of 4 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store Ottawa, Ontario
I had a Adcom GFA 555 and drove it too hard - right channel failed - underpowered for the size of speakers. Picked up this amp based on the recommendation of staff at L&M and wow - now this is how my Cerwin Vega E-715 were suppose to sound. Love the amp lots of power for my home audio man cave.
Posted by Eric Dewhirst on Apr 22, 2013
Awesome value. 2 of 3 customers found this review helpful
Features
Quality
Value
Overall
Product Experience I own it
Closest Store New Minas, Nova Scotia
Purchased this amp as my old Yamaha one was clipping. The clipping was because I added a pair of Yorkville 18" passive subs in parallel to the mains and the old amp couldn't handle such a low resistance, probably near 2 ohms. This amp handled it without a hiccup, could even go a ton louder than the previous 350w @ 8 ohm x 2 Yamaha. Great solid constucition, easy to use and some limiting features that I haven't pushed yet. How can you go wrong for this price.
Posted by D. Smith on Mar 24, 2013
