Turbosound iNSPIRE iP12B 1000W 12'' Powered Subwoofer

1,000 Watt Powered 12" Subwoofer with Dual Amplifiers for Satellite Speakers, KLARK TEKNIK Spatial Sound Technology, Digital Mixer, Remote Control via iPhone/iPad and Bluetooth Audio Streaming

The 1,000-Watt INSPIRE iP12B powered subwoofer produces high levels of low-end punch, with the definition and clarity typically reserved for much larger systems. Equipped with a dedicated 600-Watt Class-D amplifier for the 12" long-excursion Low-Frequency (LF) driver, and 2 x 200-Watt amps for your passive satellite speakers, the iP12B is ideally-suited for small to medium-sized performance venues, houses of worship, boardroom presentations, nightclubs, and much more.

Lightweight (only 22.3 kg / 49.2 lbs) and easy to transport, the iP12B also features a 3-channel digital mixer with industry-leading KLARK TEKNIK Digital Sound Processing (DSP), Class-D amplifier and Spatial Sound technologies - plus convenient Bluetooth stereo audio streaming and iPhone/iPad remote control.

Put simply, this cool-running system delivers amazingly-deep, chest-pounding bass that will keep the party going all night long.

Features
• Powered 12" subwoofer for portable PA applications and high quality music playback
• KLARK TEKNIK's revolutionary SST (Spatial Sound Technology) for creating 3D acoustic environments
• 1,000 Watt power, multi-channel KLARK TEKNIK Class-D technology
• 600 Watt high excursion 12" subwoofer for low distortion sub-bass response
• Dual 200 Watt amplifiers included for stereo satellite speakers
• 3 channel digital mixer with gain setting recall
• Comprehensive remote control via Apple iPhone/iPad*
• High quality Bluetooth• stereo audio streaming
• DSP presets for application type and speaker positioning
• Intuitive single rotary control user interface with LCD display for ease of navigation
• Road worthy birch plywood enclosure with hard wearing semi matt black paint finish
• Integrated protective perforated steel mesh grille
• Integral ergonomic carrying handles for ease of portability
• 35 mm pole mount to support satellite speaker

Technical Specifications

System
Frequency Response: 45 Hz - 150 Hz +/-3 dB
38 Hz - 200 Hz -10 dB
Nominal Dispersion: Half space
Maximum SPL: 120 dB
Crossover type: Active
Transducers: 1 x 305 mm (12") LF driver
Limiter: Peaks and RMS

Amplifier
Maximum output power*:
- Subwoofer: 600 W
- Satelites: 2x 200 W
Type: Class-D
Protection: Short circuit, open circuit, thermal

Connectors
Output L / R: 2 x Neutrik speakON*, NL4, pins 1+ / 1-
Input A / B: 2 x combo jack / XLR
Sensitivity: 4 dBu, nominal
Input impedance: 16 kΩ unbalanced, 33 kΩ balanced
Maximum input level: +22 dBu
Link output: XLR
Mains supply: IEC mains connector with integrated power switch

Controls
Hardware: Rotary push-encoder
Software: iOS interface via Bluetooth

DSP
Factory EQ presets: Positioning, sound mode, phase
Display: LCD 128 x 32, blue, backlit
Equalisation: Bass, middle and treble
Crossover: High pass L-R 24dB/oct
Protection: Lock-out function for all settings

Bluetooth Wireless Technology
Frequency range: 2402 MHz ~ 2480 MHz
Channel number: 79
Version: Bluetooth 4.0 dual mode
Output: 8 dBM
Compatibility: Supports A2DP 1.2 profile
Maximum communication range: 30 m (without interference)
Connectivity: Master-slave: stereo pairing link

Power Supply
Power consumption: 110 W @ 1/8 max power
Voltage (fuses): 100-120 V~, 50/60 Hz (T 6.3 A H 250 V)

Enclosure
Dimensions (H x W x D): 485 x 420 x 500 mm (19.1 x 16.5 x 19.7")
Net weight: 22.3 kg (49.2 lbs)
Construction, base: 15 mm (5/8") birch plywood sub
Finish: Semi matt black paint
Grille: Powder coated perforated steel
