Eventide's Flagship Multi-Effects Processor
The H9000 continues Eventide's unbroken tradition of delivering industry-leading signal processing power to the pro audio community. The H9000 comes loaded with 1600 unique algorithms from recreations of beloved classics to Eventide's latest and greatest effects. The wealth of included effects will offer users many years of exploration and inspiration.The H9000 features four quad core ARM processors serving as 16 DSP engines, eight channels of pristine analog audio I/O, AES/EBU, ADAT, and 16 USB audio channels. The H9000 is 8 times more powerful than the H8000FW, and 16 times more powerful than Eventide's popular H9 stompbox.
The H9000 comes loaded with 1600 unique algorithms from the H8000 and the H9 with over 500 presets covering reverb, delay, modulation, pitch shifting, distortion, and more. Multi-channel algorithms include 5.1 halls, chambers, plates, rooms, booths and various ambient spaces.
The blank front panel H9000R requires the full-featured version of emote. The H9000's remote control application, emote, is now available for users working 'in the box' or over an audio network.
Features
- Four quad core ARM processors: 16 DSP engines
- Analog audio I/O: 8 channels
- USB audio: 16 channels
- AES/EBU, ADAT, S/PDIF: Up to 8 channels
- Network audio options: 32 channels per expansion card. Three expansion slots for optional audio connectivity. Dante and MADI available
- Hardware Meters: 8 assignable LED meters - front panel version only
- emote: Remote control software app for Mac/Windows and plug-in for DAWs
- FX Chains: Innovative approach for setting up and managing complex effects
- Direct I/O: World-class digital audio interface
- Comprehensive Live Controls: MIDI, Expression Pedals, Auxiliary Switches and USB controllers
- Preset portability: Store and recall presets using USB thumb drives
- Network control & software updates: LAN and WiFi connectivity
Specifications
Analog Audio I/O
Physical Connections
Stereo I/O via XLR
8 Channel I/O via DB25 (Tascam standard)
Audio Specs
SNR (A Weighted):
44.1 kHz: > 120dB
48 kHz: > 114dB
96 kHz: > 114dB
THD:
44.1 kHz: < 0.002%
48 kHz: < 0.002%
96 kHz: < 0.002%
The H9000's XLR analog audio output jacks are male. Pin #1 is ground. Pin #2 is +phase (hot) and pin #3 is -phase.
Digital Audio I/O
Sample Rates: 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Digital Inputs/Outputs:
• 16 Channels of USB audio. 44.1 kHz - 96 kHz. USB can be used in conjunction with any other Digital I/O.
• AES DB-25: 8 channels of AES 24-bit at 44.1 kHz - 96 kHz. Tascam standard.
• AES XLR: 2 channels of AES at 44.1 kHz - 96 kHz
• S/PDIF RCA: 2 channels at 44.1 kHz - 96 kHz
• S/PDIF Optical: 2 channels (Only 44.1 kHZ and 48 kHz)
• Optical (Toslink): 8 channels of ADAT (Only 44.1 kHZ and 48 kHz)
Network Audio I/O
Expansion slots: 3
Dante support: Yes
MADI support: Yes
Control I/O
Remote Control Inputs
• Up to two foot pedals, or four 5V control inputs, or six foot switches, or combination.
• Stereo 1/4" connectors. The sleeve is ground reference, the ring is +5 volts (source), and the tip is an analog signal from 0 to 5 volts. Connect either foot switches, foot pedals, or control voltage sources.
Remote Control Outputs
• 2 isolated relay closures, rated at 30Vdc 1A. Relay #1 is connected between ring and sleeve, while Relay # 2 is connected between ring and tip. These connections are electrically isolated from the H9000.
MIDI Connections
• 5 pin DIN output and thru
• 7 pin DIN input with output capability
Physical
Size (h x w x d): 3.5" x 19" x 12.5" (8.9 x 48.3 x 31.7cm)
Weight (net): 14 pounds (6.4kg)
Media
