Empress Effects Zoia Modular Synth Pedal
Additional Photos:
FEATURES
• 80+ Modules and Growing - ZOIA comes packed with a vast collection of modules to create just about anything you can dream up. With ZOIA the only limit is your imagination!
• Create your own effects, synths, control devices, and more! - Oscillators, LFOs, filters, bit crushers, envelope followers - these are just a handful of the included modules that can be connected in almost any way imaginable. If you can dream it up, you can create it!
• 20+ Ready-Made Effects Modules - Pre-built effects modules such as reverbs, delays, chorus', flangers, overdrives and more.
• Up to 64 Patches - Create and save up to 64 patches that can be easily recalled during live performance.
• Swap and Share Patches - Join the community of ZOIA users on patchstorage.com to try out other users patches, or upload your own awesome creations to share with the world.
• SD Card Included - Load and save patches to/from ZOIA. Download the newest firmware from empresseffects.com and load onto the ZOIA with the included SD card.
• OLED Display Screen for Easy Editing - View all of ZOIA's module and parameter information on the high resolution OLED display screen.
• Control Port and MIDI Connectivity - Dedicated control port and MIDI 1/8" in/out jacks allow you to connect a huge range of external devices to control any or all of ZOIA's functions and parameters. 1/8" to MIDI dongles included.
• Customizable Patch Recall System - The on-board stompswitches can be used in either scrolling - or bank-style preset modes, for quick on-the-fly patch recall that suits your workflow.
• Built-In Help - Almost like having a built in manual, the dedicated help function will give you quick information at a glance about ZOIA's various modules and options.
• High-Quality Audio - 48kHz sampling, with 24 bit conversion and 32 bit internal processing.
• Low-Noise Signal Path - Features extremely low noise operation with a signal to noise of > 105dB
SPECIFICATIONS
Input Impedance: > = 1MΩ
Output Impedance: 100Ω
Frequency Response (-3dB): 10Hz 23.4kHz
Total Harmonic Distortion: 0.22%
Dynamic Range: 105.5 dBA
Input Headroom (no pad): +0.5 dBu
Input Headroom (6dB pad): +5.7 dBu
Input Headroom (12dB pad): +10.8 dBu
Output Headroom: +16.2dBu
Power Input Connector: 2.1mm Barrel Connector
Power Input Voltage: 9V DC (center negative)
Required Current: 300mA
Height (enclosure only): 1.75"
Height (including controls): 2.625"
Length: 5.7"
Width: 3.75"
Weight: 1.5lbs
