Tascam ML-16D 16-channel Analog/Dante Converter
Additional Photos:
Product Videos :
The ML-16D has 2 D-Sub inputs and 2 D-Sub outputs, which can easily be connected to any of the many devices that utilize D-Sub connectors such as microphone preamplifiers, large and small format console mixers, audio interfaces, amplifiers, and euro block connector devices. This simple, yet elegant, solution enables audio to be quickly and easily inserted into or extracted from the Dante audio stream.
Features
• Dante focused interface for connection of external audio into or out of a Dante audio network
• 16 channel analog line input and 16 analog line outputs (48k/96kHz) using four D-Sub connectors
• Dual redundant Ethernet jacks which support both primary and secondary connections
- Dante primary and secondary connectors support redundancy
- AES67 and Ravenna compatible
- Dante Controller for flexible routing
• Up to 96kHz/24-bit quality
• Equipped with a signal/overload indicator that enables level monitoring of analog input/output signals
• Reference level dip switches for selectable DBu level metering
• LED display for signal level and overload per input/output channel
• Firmware updatable via Dante port
• Equipped with D-sub 25-pin connectors as line input/output connectors
• 1U rack mount size
Specs
Sampling frequency: 44.1k / 48k / 88.2k / 96k Hz
Quantization bit rate: 16 / 24-bit
Power: AC 100 - 240V, 50/60Hz
Power consumption: 14W
Dimensions (WHD): 19.0" 1.77" 11.96" / 483 45 303.8 mm
Weight: 7.3 lbs. / 3.3 kg
Operating temperature range: 32˚F to 104˚F / 0˚C to 40˚C
Standard accessories: Power cord, Rackmount screw kit, Owner's Manual
Audio performance
ANALOG IN → Dante OUT
Frequency response:
• 20Hz to 20kHz +0.1dB/0.5dB (16dBFS input, 44.1k/48kHz sampling frequency, JEITA)
• 20Hz to 40kHz +0.1dB/0.5dB (16dBFS input, 88.2k/96kHz sampling frequency, JEITA
Distortion (THD+N): 0.001% or lower (1dBFS input, 1kHz, 44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
S/N ratio: 113dB or higher (44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
Crosstalk: 115dB or higher (1kHz, 44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
Dante OUT → ANALOG IN
Frequency response:
• 20Hz to 20kHz +0.1dB/0.5dB (16dBFS input, 44.1k/48kHz sampling frequency, JEITA)
• 20Hz to 40kHz +0.1dB/1.0dB (16dBFS input, 88.2k/96kHz sampling frequency, JEITA)
Distortion (THD+N): 0.001% or lower (1dBFS input, 1kHz, 44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
S/N ratio: 110dB or higher (44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
Crosstalk: 115dB or higher (1kHz, 44.1k/48k/88.2k/96kHz sampling frequency, JEITA)
