PreSonus Studio 26C 2x4 USB-C Audio Interface
Additional Photos:
Product Videos :
One for the Road
Studio 26c: The portable, affordable, ultra-high-def USB-C audio interface
Ideal for DJs, mobile musicians, and electronic musicians who want excellent audio quality in a sturdy, portable form factor, the bus-powered Studio 26C 2-in, 4-out audio interface records at up to 192 kHz and features mic/line/instrument inputs, DC-coupled line outputs, MIDI I/O, and a Cue Mix A/B button. A complete, all-in-one recording package, the Studio 26C comes with PreSonus award-winning Studio One Artist music production software for macOS and Windows and includes USB-C to USB-C and USB-C to USB-A cables for compatibility with most computers.
The 2-in, 4-out Studio 26C audio interface features USB-C computer connectivity and includes combo mic/instrument/line inputs with +48V phantom power for condenser mics; balanced, -inch TRS, line-level main outputs; and an output level control. All line-level outputs are DC coupled, enabling them to send control voltages. A Cue Mix A/B function lets you toggle between two mixes while monitoring through headphonesperfect for DJs and to listen in on a performers monitor mix. The Studio 26Cs built-in MIDI interface enables connection to a keyboard, sound module, or control surface.
Superior Sound
The Studio 24C operates at up to 192 kHz for ultra-high-definition recording and mixing. High-quality converters on every input and output and PreSonus professional-grade XMAX-L mic preamps enable you to capture complex musical harmonics smoothly and naturally, with no audible distortion.
Includes Studio Magic Plug-in Suite.
This suite of plug-ins adds a wealth of fresh sounds and effects to Studio One. Cherry-picked from the first names in virtual instruments and effects, each plug-in brings a different flavour of practical magic to your songs. These plug-ins aren't gimmicky one-trick ponies - these are real-deal workhorses that you'll rely on for countless mixes.
2018 Plug-In Suite Includes*:
• maag Audio - EQ2 Equalizer
• brainworx - BX Opto Compressor
• Lexicon - MPX-I Reverb
• SPL - Attacker Transient Shaper
• Klanghelm - SDRR2Tube Saturator
• Ouput - Movement Rhythm Processor
• Arturia - Analog Lab Lite Virtual Synth and Keys
*Content of Plug-In Suite is subject to change. Some conditions apply.
Features
Input/Output
• Simultaneous I/O up to 2 inputs/4 outputs
• 2 mic/instrument/line inputs with XMAX-L mic preamps
• 2 balanced 1/4 TRS main outputs
• DC coupled for sending control voltages
• 2 balanced 1/4 TRS line outputs for monitor mixing
• DC coupled for sending control voltages
• 1 stereo headphone output
• MIDI In/Out
Meters, Controls, and Features
• Direct monitoring
• Cue mix A/B (for headphone output)
• Front-panel level controls for main outputs
• True +48V phantom power for condenser microphones (global)
• 4 ladder-style LED level meters (2 input, 2 main output)
Integrated Software
• Studio One Artist
• Studio Magic Plug-in Suite
Digital
• USB-C port (USB 2.0)
• 24-bit resolution
• 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
Physical
• Road-rugged construction with all-metal chassis and metal knobs
• USB bus-powered
Specifications
General
Sample Rates: 44.1, 48, 88.2, 96, 176.4, or 192 kHz
Converter Resolution: 24 bit
Converter Dynamic Range: 114 dB
Converter Dynamic Range: 114 dB
Microphone Inputs
Maximum Level: +4.5 dBu (balanced, min gain)
Gain Range: 70 dB
Frequency Response: 20 Hz - 20 kHz (0.1 dB, min gain, 48 kHz)
Dynamic Range: 110 dB (A-wtd, min gain)
THD + N: 0.004% (1 kHz, -1 dBFS, unity gain)
EIN: -125 dBu (max gain, 150Ω, A-wtd)
Input Impedance: 1.6 kΩ
Phantom Power: +48 VDC (10 mA total)
Line Inputs
Maximum Level: +19.5 dBu (balanced, min gain)
Gain Range: 70 dB
Frequency Response: 20 Hz - 20 kHz (0.1 dB, min gain, 48 kHz)
Dynamic Range: 110 dB (A-wtd, min gain)
THD + N: 0.007% (1 kHz, -1 dBFS, min gain)
Input Impedance: 10 KΩ
Instrument Inputs
Maximum Level: +14 dBu (unbalanced, min gain)
Gain Range: 70 dB
Frequency Response: 20 Hz - 20 kHz (0.15 dB, 48 kHz, min gain)
Dynamic Range: 110 dB (A-wtd, min gain)
THD + N: 0.008% (1 kHz, -1 dBFS, min gain)
Input Impedance: 1 MΩ
Line Outputs (Mains)
Type: 1/4" TRS Female, DC Coupled*
Maximum Level: +10 dBu (balanced)
Frequency Response: 20 Hz - 20 kHz (0.1 dB, unity gain, 48 kHz)
Dynamic Range: 108 dB (A-wtd)
THD + N: 0.0015% (1 kHz, -1 dBFS)
Line Outputs (3/4)
Type: 1/4" TRS Female, DC Coupled
Maximum Level: +10 dBu (balanced)
Frequency Response: 20 Hz - 20 kHz (0.1dB, unity gain, 48 kHz)
Dynamic Range: 113 dB (A-wtd)
THD + N: 0.008% (1 kHz, -1 dBFS)
Headphone Outputs
Maximum Power: 30 mW/channel (56Ω load)
Frequency Response: 20 Hz - 20 kHz (0.2 dB, 56Ω load, 48 kHz)
Dynamic Range: 104 dB (A-wtd, 56Ω load)
THD + N: 0.009% (1 kHz, -1 dBFS, no load)
Impedance Working Range: 32Ω to 300Ω
Physical
Height: 1.75" (44 mm)
Width: 7" (180 mm)
Depth: 5.5" (144 mm)
Weight: 1.6 lbs. (0.7 kg)
Computer System Requirements
Mac
• Mac OS X 10.8.5 64-bit or later
• Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
• 4 GB RAM (8 GB or more recommended)
Windows
• Windows 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, • Windows 10 x64/x86
• Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
• 4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
• USB-C or USB-A 2.0 port
• 32 GB hard disk space
• PreSonus Universal Control 2.0 or higher
• Monitor with 1366x768 resolution (high-dpi monitor recommended)
• Multitouch-enabled monitor required for touch operation
