Departments > Pro Audio & Recording > Audio Interfaces & DAW Controllers > USB Audio Interfaces > PreSonus > Studio 1824c 18-inx24-out 192kHz USB-C Audio Interface

PreSonus Studio 1824c 18-inx24-out 192kHz USB-C Audio Interface

SKU: # 707157   |   Model: # 2777700402   |    Product Reviews3 Reviews  Write a Review

Studio 1824c 18-inx24-out 192kHz USB-C Audio Interface

Additional Photos:

Studio 1824c 18-inx24-out 192kHz USB-C Audio Interface
Sale Price: $579.99 CDN
Original Price: $689.99 CDN
or from $61 CDN/mo
Notify Me

Buy Online

 Add to Cart

Buy In-Store

The full-featured, ultra-high-def, USB-C audio interface.


The Studio 1824c 192 kHz USB-C audio interface is ideal for producers interested in recording full bands, including multi-channel drums. It records up to 18 simultaneous inputs and features 8 XMAX Class A mic preamps, as well as MIDI I/O. Its 20 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with included Studio One Artist music production software and UC Surface control software.

The Studio 1824c audio interface features USB-C computer connectivity and records up to 18 simultaneous inputs, including two combo mic and switchable line/instrument inputs and six mic/line inputs, all with XMAX mic preamps and +48V phantom power. Digital inputs include eight channels of ADAT Optical I/O (four channels at 96 kHz) and stereo S/PDIF I/O. In addition to the main L/R outputs, you get eight DC-coupled line-level outputs that can send control voltages. You also get two headphone outputs. A built-in MIDI interface enables connection to a keyboard, sound module, or control surface.

FEATURES

Input/Output
• Up to 18 inputs/20 outputs simultaneously (8x8 at 192 kHz)
• 2 mic/instrument/line inputs with XMAX Class A mic preamps
• 6 mic/line inputs with XMAX Class A mic preamps
• 8 channels of ADAT Optical I/O (4 channels at 96 kHz)
• 2 balanced 1/4" TRS main outputs
• 8 balanced 1/4" TRS line outputs for monitor mixing
• 2 stereo headphone outputs with individual level controls
• MIDI In/Out
• Stereo S/PDIF digital I/O
• 1 USB-C 2.0 port
• BNC word clock output

Integrated Software
• Studio One Artist for Mac and Windows
• UC Surface control software for Mac, Windows, iPad, and Android
• Studio Magic Plug-in Suite

Meters, Controls, and Features
• 18x8 onboard DSP monitor mixer
• Front-panel level controls for main outputs
• Mono and Mute buttons for the main outputs
• True +48V phantom power for condenser microphones (global)
• 10 ladder-style 8-LED level meters (8 input, 2 main output)

Digital
• USB-C port (USB 2.0)
• 24-bit resolution
• 44.1, 48, 88.2, 96, 176.4, and 192 kHz sampling rates

Physical
• 1U rack-mountable
• Road-rugged construction with all-metal chassis and metal knobs
• Weight: 2.2 kg (4.8 lbs)
• Dimensions (H x W x D): 44 mm x 483 mm x 140 mm (1.75" x 19"x 5.5")

Q & A


There are currently no questions for this product.

Reviews


18.224.31.82
Mozilla/5.0 AppleWebKit/537.36 (KHTML, like Gecko; compatible; ClaudeBot/1.0; [email protected])
1824c home studio 0 of 0 customers found this review helpful
Features
Quality
Value
Overall
Product Experience   I own it
Closest Store   Richmond, British Columbia
I recently purchased this to replace my audiobox ione, I am new(ish) to home recording so I wanted something versatile and with enough inputs to track the basic rock music instruments I use at home. This does that so well, was instantly recognized by my laptop and other than a small issue updating the drivers (had to change the usb port for it to work) I had no issues. It doesn't come with rack mount screws which I learned when I went to install it in my desk so be aware of that!
Posted by Mason N on Jan 25, 2024
Was this review helpful? Vote helpful Vote not helpful flag this review
using 2 presonus 1824c's to get 16 channels. 5 of 5 customers found this review helpful
Features
Quality
Value
Overall
Product Experience   I own it
Closest Store   Cambridge, Ontario
Hello how to connect 2 1824c's together. using Universal Control 4.1 Connect optical cable on main unit in to second unit out Connect optical cable on second unit in to man unit out I don't think you need both for just recording, but I use both Start computer with both 1824c's connected but turned off. with UC (Universal Control) running. Start your main 1824c. (note serial number in bottom right-hand corner) mine ends in (8). let light flash red, blue, red, blue. you can wait till the light settles on purple, but I never do. Set main 1824c to ADAT. Start your second 1824c. (note serial number in bottom right-hand corner) this one ends in (4). Both lights should flash for a second then turn blue. Set second 1824c to Internal {I use the serial numbers to keep track of which ones which. in UC} Before you can use both you must set the mixer in UC. From UC click the second 1824c (S#4 for me) {the one set to Internal} the mixer will come up. Set all faders from 1 to 8 to 0db or as close as you can get it, for me it's 0.01 db. [very tedious and a pain in the ass]. And set balances as so: 1,3,5,7. to left and 2,4,6,8. to right. Then in the mix section ADAT 1/2 set fader 1 to 0db. balance left. ADAT 1/2 set fader 2 to 0db. balance right. ADAT 3/4 set fader 3 to 0db. balance left. ADAT 3/4 set fader 4 to 0db. balance right. ADAT 5/6 set fader 5 to 0db. balance left. ADAT 5/6 set fader 6 to 0db. balance right. ADAT 7/8 set fader 7 to 0db. balance left. ADAT 7/8 set fader 8 to 0db. balance right. You should be good to go. Just remember every time you start. Start computer, the main 1824c and let light blink red, blue, a couple times then start the second one.
Posted by steve on Aug 8, 2023
Was this review helpful? Vote helpful Vote not helpful flag this review
Incredible product at great price. 6 of 6 customers found this review helpful
Features
Quality
Value
Overall
Product Experience   I own it
Closest Store   Burlington, Ontario
I’ve been using this unit for just more than a year now. Sound quality, reliability and ease of use are all exceptional. Mostly used for tracking live drums but also occasionally for vocals, guitars and midi. Very satisfied.
Posted by Ryan on Jan 8, 2022
Was this review helpful? Vote helpful Vote not helpful flag this review
