Mesa Boogie Subway WD-800 Bass Head w/Tube Pre
Additional Photos:
Product Videos :
As in the original, the inspiring round, fat WalkAbout Tone is joined by comprehensive rotary shelving Tone controls and a semi-parametric EQ, giving you total shaping authority in the preamp. The new WD800 also features the Subway D800 Pluss highly effective HIGH PASS FILTER and a new POWER AMP DAMPING control, which allow tuning of the sub-low frequencies and power response options respectively. The POWER DAMPING choices enable you to tailor the tracking and feel of the power amp. The LOW setting produces a looser, more relaxed and blooming character reminiscent of Tube power. HIGH tightens the low end, adding punch and accuracy in tracking, while MEDIUM provides a blend of these opposite ends of the power response spectrum.
The WD-800 can perform as a stand-alone Head or be mounted in 2 Spaces within standard 19" Racks by attaching the optional Rack Ears (not included). Whether you're looking for a lightweight new main rig to replace your heavy linear amp with a bigger, wider sound and more complex harmonic content than the lightweight options you've tried, or just a compact, portable head for everyday gigging and recording that will fill the room with luscious Tone, the new WD-800 covers bases with power and versatility to spare. Not exactly a WalkAbout or a Subway, but rather everything great about both combined in a super-responsive compact, lightweight, big-power platform, just as you ordered!
Features
- Wattage: 800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms
- Power Amp Type: Light-Weight Class D Power Amp & 8/4 or 2 Ohm Impedance Switch & Variable Damping Control
- Preamp: 2-Stage Class A Vacuum Tube Preamp w/ 1x Mesa 12AT7
- EQ / Dynamics Control: Variable High-Pass Filter (25Hz-125Hz), Fully Active 5-Band EQ (+/- 12dB) featuring Bass, Treble and a selectable/bypassable 3-Band Semi-Parametric EQ Sweepable from 80Hz-1KHz, 150Hz-2.5KHz & 300Hz-5KHz respectively, and a Passive Mid Control
- Footswitchable Functions: External Switching Jack for Parametric EQ & Mute (Footswitch Sold Separately)
- USB Power Outlet, Headphone Output and Auxiliary Input
- Includes Gig Bag with Shoulder Strap
Specs
Amp Type: Tube Preamp & Class D Power Amp
Chassis Material: Aluminum
Preamp Tubes: 1x Mesa 12AT7
Power Amp Power Devices: Class D Power Amp
Wattage(s) Quick Reference: 800 Watts @ 4 or 2 Ohms / 400 Watts @ 8 Ohms
Power Amp Details: Light-Weight, Compact Class D Power Amp with Variable Damping Control, Protection, Limit & 2-Ohm Load LED Indicators
Convection or Fan Cooling: Fan Cooled
Instrument Input Options: 1x 1/4" with Active/Passive Switch
Preamp Details: 2-Stage Class-A Preamp featuring Input Gain with Clip Indicator (O/D LED), Variable High-Pass Filter (25Hz-125Hz), Fully Active 5-Band EQ (+/- 12dB) featuring Bass, Treble and a selectable/bypassable 3-Band Semi-Parametric EQ Sweepable from 80Hz-1KHz, 150Hz-2.5KHz & 300Hz-5KHz respectively, Passive Mid Control & Master Volume
Effects Loop: Fully Buffered Series FX Loop
Solo Level Control: n/a
Direct Line Output (DI): Balanced XLR Out with Pre/Post, Line/Mic & Ground Lift Switches
Tuner Output / Mute: Tuner Output (back panel) with Play/Mute Switch (front panel) and External Mute Switching Jack (back panel)
External Switching Jack Options: External Switching Jack for Parametric EQ & Mute (Footswitch Sold Separately)
Speaker Outputs: 2 - Speakon Output Jacks (no 1/4" speaker jacks) - 8, 4 or 2 Ohms
Headphone Output: Yes
Weight: 7 lbs.
Dimensions: 4" H x 12" W x 11.375" D
Media
Q & A
Reviews
Protect your investment with the Long & McQuade Performance Warranty
A warranty can be a very important factor when making a buying decision. Because repairs can be very expensive in terms of parts and labour costs, manufacturers usually only provide one year limited warranties that generally only cover items that malfunction due to a manufacturer’s defect. With an important purchase such as a musical
instrument or piece of studio gear, however, many people want to have the peace of mind in knowing that their investment will be protected should the product no longer be performing at 100%.
Because of this, Long & McQuade provides our customers with a FREE one-year Performance Warranty on most of our products. The Long & McQuade Performance Warranty supplements the manufacturer’s warranty to ensure that our customers receive complete “no hassle” warranty coverage within their first year.
How does the Long & McQuade Performance Warranty differ from most manufacturers' warranties?
- Performance Guarantee: Normal wear and tear is covered, so your product will be performing as well as the day you purchased it for the entire duration of the coverage. Band and Orchestral Performance Warranty does not include replacing pads or cleaning for woodwind instruments, unless deemed necessary by our repair staff. Ultrasonic cleaning for brass instruments will be provided if deemed necessary by our repair staff, but is not routinely offered under the Performance Warranty.
- Product Replacement: If your product cannot be fixed or costs too much to fix, we will replace it with the equivalent model for no additional charge. If this is not possible, a full refund will be provided.
- No Lemon Policy: Your product will be replaced should the same problem occur multiple times.
- Convenient: Easy drop off and pick up of the product at any Long & McQuade location.
- Guitar Setup: Guitars purchased at Long & McQuade come with 1 free setup, to be redeemed within 1 year for new guitars and 90 days for used guitars.
- Loaners Available: A loaner product may be given while the product is being repaired.
- Power Surge Protection: Your product is covered even if damaged from a power surge.
- Accessory Coverage: Any peripheral devices or accessories that come with your product (i.e. foot pedal, case) are also covered.
- Commercial Use Coverage: Music and recording professionals who purchase gear for “heavy-use” commercial purposes will still be covered.
Long & McQuade reserves the right to restrict the purchase of additional years of Performance Warranty. Used products come with a 3-month Long & McQuade Performance Warranty. Some products (i.e. computers, software, cymbals and other items) are covered only by the manufacturer‘s warranty. Consumables (i.e. strings, reeds, drum sticks, batteries, tubes, cross faders) are excluded as they are designed to be replaced. Cosmetic Damage, Accidental Damage, or problems caused by Humidity or Temperature Issues are not covered. Speakers damaged by overpowering are generally not covered. Our coverage does not provide compensation for loss of use. As of June 2018 the Performance Warranty is no longer transferable. The warranty is only valid in Canada.
Purchasing additional years of coverage
Some manufacturers provide warranties for longer than 1 year; however, these are usually limited warranties that do not provide the same coverage as the Long & McQuade Performance Warranty. Customers interested in more complete and convenient (but not necessarily longer) coverage are still able to purchase additional years of the Performance Warranty.
If you are interested in receiving this coverage for longer than one year, you have the option of purchasing additional years of the Performance Warranty. The pricing is as follows:
- NEW products: Starting at 4% of the current new selling price to double the warranty from 1 year to 2 years. Starting at 4% for each additional year.
- USED products: Starting at 4% of the current new selling price to increase the warranty from 3 months to 1 year. Starting at 4% for each additional year.
- GUITARS: 4% of the current new selling price to double the warranty from 1 year to 2 years. 4% for each additional year. $45 maximum. An additional free setup is not included with additional purchased years of Performance Warranty.
- BAND and ORCHESTRAL instruments: 4% of the current new selling price to double the warranty from 1 year to 2 years. 4% for each additional year.
