Tascam Model 24 Multitrack Recorder with Integrated USB Audio Interface and Analog Mixer
Additional Photos:
The TASCAM Model 24 was developed for easy and immediate operation, with everything you need placed right at your fingertips. 100mm faders allow for precise control over volume. A full set of familiar EQ and Auxiliary knobs remove the need for menu diving, and all input/output connections are all on the surface for quick and easy access.
Featuring 16 high-grade TASCAM mic preamps in addition to multiple sets of stereo line inputs, the Model 24 delivers studio quality audio performance right from the start. When it's time to record The TASCAM Model 24 allows musicians and engineers to capture up to 24 tracks simultaneously (at 24bit/48kHz resolution) directly to the SD card, with the ability to support punch in/out 8 tracks at the same time. And once the take is done, the Model 24 can easily playback any or all of the recorded tracks through the console for immediate mixdown.
Flexible Connectivity
In addition to the studio quality mic preamps and powerful EQ and routing options the Model 24 features a dedicated stereo channel 1/8", dual RCA Bluetooth(TM) connectivity. This allows users to easily integrate mobiles devices into the mix for rehearsal playback, walk-in music and more. Finaly, the TASCAM Model 24 can also act as a powerful audio interface and will connect directly to your PC or Mac for easy integration with your DAW of choice.
Features at a glance
• All-in-One, Multitrack Recorder with 22 channel Mixer and USB Audio Interface
• WAV 48kHz/24-bit, 24 channel multitrack recording to SD, SDHC and SDXC cards
• Built-in USB Audio Interface to send/receive audio data to/from DAW
• 22 Inputs (20 Balanced, 12 Monaural, and 4 Stereo)
• 16 TASCAM Microphone Preamps
• Input Mode switch on every input channel
• TASCAM Ultra-HDDA Mic Pre-amp (Channels 1 to 12)
• Preamp Gain Controller with Overload indicator (Channels 1 to 12)
• 3-band EQ with a sweepable mid-range frequency (Channels 1 to 12)
• 100kHz Low-cut Filter (Channels 1 to 12)
• 7-band Graphic EQ
• 16 Pre-set Effects
• 100mm Long-throw Faders for precise adjustment
• Mute, Main/Sub, PLF switches on every input channel
• Bluetooth input supporting both AAC and SBC codecs
• SUB Outputs via XLR Balanced and RCA Unbalanced connectors
• LINE Inputs via RCA Pin and ⅛" Stereo Mini jacks
• 3 AUX Outputs (Monitor 1, Monitor 2, FX)
• 1 Stereo Output for Control Room
• Phantom Power (+48V)
• 1/4" Stereo Headphone Output
• Backlit buttons for key operations such as REC and Play
• Multi Jog-dial for quick menu operation
• 12-segment LED Output Level Meters
System Requirements
Windows
Supported OS: Windows 10 (April 2018 Update) New, Windows 8.1, Windows 7
Compatible Computers: Windows-compatible computer with a USB2.0 port
CPU: Dual core / 2GHz or faster
Memory: 2GB or more
Driver: USB Audio Class 2.0, Model 24 ASIO2.0, WDM (MME)
Screen Resolution: 1280 800 Dots or more
Macintosh
Supported OS: macOS High Sierra (10.13), macOS Sierra (10.12), OS X El Capitan (10.11)
Compatible Computers: Apple Macintosh computer with a USB2.0 port
CPU: Dual core / 2GHz or faster
Memory: 2GB or more
Driver: Core Audio
Screen Resolution: 1280 800 Dots or more
